Product Details:
|
| Name: | Ceramic Ferrules Fiber Optics | Color: | White |
|---|---|---|---|
| Connector Type: | LC | Polish: | APC |
| Material: | Ceramic | OEM: | Available |
| High Light: | fiber optic parts and accessories,fiber optic cable assembly |
||
Fiber Optic Assembly LC / PC Ceramic Ferrule , Fiber Optic Cable Accessories
Applications
• CATV
• Telecom network
•Optical test equipment
•Local area networks
•Wide area networks
•Data processing Networks
Features
•Excellent materials
•Good compatibility
•Good reliability and stability
•Precise dimension
•Low insertion loss, and high return loss
•High intensity, good anti-erosion and anti-aging performance
Specifications
| Item | SC/PC Series | SC/APC Series | LC/MU Series |
| Length | 10.50±0.01mm | 10.50±0.01mm | 6.50±0.01mm |
| Outer-diameter | 2.4990±0.0005mm | 2.4990±0.0005mm | 1.4990±0.0005mm |
| Inner-diameter | 0.125~0.128mm | 0.125~0.126mm | 0.125~0.128mm |
| Concentricity | ≤1um, ≤3um | ≤0.5um, ≤1um | ≤1um, ≤3um |
| Endface Type | Spherical Surface | Step or Conical | Spherical Surface |
