Product Details:
|
| Color: | Different Color | Name: | MPO TO LC Patch Cable |
|---|---|---|---|
| Connector: | MPO To LC | Mode: | Single Mode |
| Core: | 12 Cores | OEM: | Available |
| High Light: | mpo fiber cable,mpo to mpo cable |
||
MPO/MTP-LC 12 Core Fiber Optic Patch Cord
Applications:
Data communication network
Optical system access network
Storage area networking fiber channel
High density architectures
Feature:
1. Utilize MPO/MTP Connectors
2. Rapid Deployment
3. Factory terminated
4. 100% tested (test data supplied)
5. High density cable
6. Optimized performance
7. Compliant to directive 2002/95/EC (ROHS) and REACH SVHC
8. MPO connector complies with IEC-61754-7& EIA/TIA-604 -5
Specifications:
| Model | SM | MM | |
| Connector fiber count | 8,12,24 Core | ||
| Polish | PC,APC | PC | |
| color | Standard(Green),Elite(Yellow) | Standard(Beige),Elite(Aqua) | |
| Inserting loss | Standard | ≤0.7dB | ≤0.5dB |
| Elite low loss | ≤0.3dB | ≤0.3dB | |
| Return loss | PC≥50dB,APC≥60dB | ≥30dB | |
| Durability(500 Mating) | ≤0.2dB | ||
| Test wavelength | 1310/1550nm |
850/1310nm |
|
