Product Details:
|
| Color: | Blue ,Red | Material: | Plastic,Metal |
|---|---|---|---|
| Connector: | ST-LC | Model: | Singlemode |
| Polish: | UPC | Name: | ST-LC Adapter |
| High Light: | fiber optic cable connectors,fiber optic fast connector |
||
Test equipment use ST to LC Optical fiber adapter Fiber Optic Connector ST-LC Male-Female
Availability:
* SC to ST - SC to FC - FC to ST - LC to FC
* LC to SC - DIN to FC - DIN to SC
Specifications:
* Insertion Loss <0.20dB
* Durability <0.20 dB typical change, 1000 matings
* Operating Temperature:-40 to + 80C
| Characteristic | SM , MM | |||
| Connector type | FC/SC/ST/LC/MU/MT-RJ/ESCON/E2000 | |||
| Diameter(mm) | 0.9,2.0,3.0 | |||
| Polishing grade | SM PC | MM PC | UPC | APC |
| Insertion loss | ≤0.3dB | ≤0.4dB | ≤0.2dB | ≤0.3dB |
| Return loss | ≥40dB | ≥50dB | ≥65dB | |
| Interchangeability | ≤0.2dB | |||
| Repeatability | ≤0.2dB | |||
| Operation temperature | -40~+85 | |||
Features:
* Low insertion loss and back reflection loss
* High precision alignment
* Nickel plated brass body
* Plastic body
* Choice of housing shape and sleeve material
* Compact design
Application:
* CATV,
* Telecommunication networks,
* Test equipment,
* Metro,
* Local Area Networks (LANs),
* Data processing networks
