CATV 19 Inch ODF Optical Fiber Distribution Frame 12 Port Core With Standard Size

    • CATV 19 Inch ODF Optical Fiber Distribution Frame 12 Port Core With Standard Size
    • CATV 19 Inch ODF Optical Fiber Distribution Frame 12 Port Core With Standard Size
  • CATV 19 Inch ODF Optical Fiber Distribution Frame 12 Port Core With Standard Size

    Product Details:

    Place of Origin: China
    Brand Name: New Light
    Certification: CE

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pcs
    Price: Negotiate
    Packaging Details: 1 piece per pack
    Delivery Time: within 2 weeks
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 1000 pcs per month
    Contact Now
    Detailed Product Description
    Color: White Core Number: 12
    Application: FTTX, FTTH Odf Fiber: Simplex,Duplex
    Name: Optical Fiber Distribution Frame OEM: Available

    CATV use 19 inch 12 core ODF optical fiber distribution frame 12 port core







    Technical Information:



    Type: Cable installation , wall mount
    Size: 40x38x14cm , 30x30x8.5cm, 40.5x38.2x8.5cm

    Capacity: 12 SC, 12 LC

    Connector options: SC, SC/APC, LC, LC/APC, ST, FC



    Features:



    1) Standard size, light weight and reasonable structure

    2) Splice tray inside changeable

    3) Can be used in 19'', 23'' standard distribution frame

    4) Suitable for ribbon and single fiber

    5) Various panel plate to fit different adapter interface

    6) Front mark on the plate is easy for identification and operation

    7) 24C, 36C, 48C, 72C 96C optional, with or without fiber optic pigtails and adapters

    8) Easy for management and operation





    Description:



    ODF with pigtails and adapters contain one ODF, adapters and pigtails. Parts are shipped separately, The installer assembles the pigtails and adapters in the ODF on site. Boxes can be supplied to contain from 12 to 192 fibers. All ODFs are withdrawable and designed for mounting in 19” racks. They are equipped with splice holders and guiding for fibers. We can also supply you with other combinations on request.





    Application:



    1) Telecommunications subscriber loop

    2) Fiber to the home (FTTH)

    3) LAN/WAN

    4) CATV



    ODF Electricity Performance:



    Environment temperature -25~55 degree
    Atmosphere pressure 70~106Kpa
    Insulating resistance >2x104 MΩ/500VDC
    Relative humidity <85%(when the temperature is below 30 ℃
    Voltage resistance strength Under the effect of 15kv/DC/1min,non-puncture,and no arc-over











    CATV 19 Inch ODF Optical Fiber Distribution Frame 12 Port Core With Standard Size
