Product Details:
|
| Name: | FTTH Drop Cable | Fiber Count: | 1 Fiber |
|---|---|---|---|
| Construction: | Self-supporting | Fiber Type: | Singlemode ,G657A2 |
| Outer Jacket Material: | LSZH | Strength Member Material: | KFRP / FRP / Steel Wire |
| Color: | Black/White | Application: | FTTH Projects |
| Packaging: | Wooden Wheel | Test Repor: | Out Package Of The Cable |
| Fiber Struction: | Figure8 | Usage: | Aerial |
| High Light: | duplex fiber optic patch cable,fiber optic drop cable |
||
White / black color G652A2 FTTH drop cable with LSZH / PVC / PE Jacket
Description :
The drop FTTH cables are with flame retardant jacket and with supporting wire, there are strengthen members inside the cables for supporting the whole cables, the whole cable meet the RoHS standards and contains no harmful components, in general, it is a highly recommended FTTH drop cables for use in the fiber to the home projects, saving time and cost.
Characteristics :
· Good mechanical and enviromental characteristic
· Anti-UV charateristics meet the requirements of relevant standards
· The mechanical charateristics meet the requirements of relevant standards
· Soft ,flexiable ,easy to lay and splice,and with big capacity data transmission
· Meet various requirements of market and clients
Features and Benefits
• Self-supporting structure, light weight, easy to install
• Durable and flame retardant LSZH sheath, low smoke zero halogen
• Excellent mechanical and environmental performance
• Steel wire as additional strength member has high tensile strength
• Two parallel FRP strength members ensure good performance of anti- electromagnetic and crush resistance
| Fiber count | 1F/2F/4F |
| Attenuation | 1310nm:≤0.36 1550nm:≤0.22 |
| Color Of fiber | Blue Orange Green Brown |
| Fiber Type | G652D/G657A1/G657A2 |
| Strength member | Steel wire/FRP/KFRP |
| Outer sheath | LSZH Lower smoke zero halogen frame retardant & UV Anti |
| Cable Diameter dimensions | 2.0( Height) × 3.0W ± 0.1 mm(width) |
| Operation temperature range | -20 ℃ to + 70 ℃ |
| Installation temperature range | -0 ℃ to + 60 ℃ |
| Transport and storage temperature range | -20 ℃ to + 70 ℃ |
| Tension Load (N) | Short term :800N Long term :500N |
| Crush Load(N) | Long term 1000 N/100mm Short term:2200N/100mm |
| Minimal installation bending radius | 30 x OD |
| Minimal operation bending radius | 15 x OD |
| Cable marking | The marking length 1meter apart , as required |
Packing
| Item | Index |
| Length and packaging | 1000m/plywood reel |
| Plywood reel size | 300*110*230mm |
| Carton size | 310*310*250mm |
| Net weight | 9kg/km |
| Gross weight | 10kg/box |
| Packaging details | wooden wheel |
Application
• Outdoor aerial application
• Used in the FTTH projects
• High performance optical network operation
• High speed optical routes in building
A high-capacity FTTH network gives you opportunities to build a competitive advantage and maintain an eco-sustainable network that consumes less power. With simple structure and light weight, self-supporting FTTH drop cable is highly recommended for the connection of outdoor and indoor cabling.
