3 Meters SC - SC Multimode Fiber Optic Cable Patch Cord Duplex With Clip OM4 cable

3 Meters SC - SC Multimode Fiber Optic Cable Patch Cord Duplex With Clip OM4 cable
3 Meters SC - SC Multimode Fiber Optic Cable Patch Cord Duplex With Clip OM4 cable 3 Meters SC - SC Multimode Fiber Optic Cable Patch Cord Duplex With Clip OM4 cable

Large Image :  3 Meters SC - SC Multimode Fiber Optic Cable Patch Cord Duplex With Clip OM4 cable

Product Details:
Place of Origin: Shenzhen , China
Brand Name: New Light
Certification: CE, ISO ,RoHS
Model Number: LC /FC /SC/ST / MPO / MTP/ MU / MTRJ
Payment & Shipping Terms:
Minimum Order Quantity: 10 pcs
Price: can be negotiated
Packaging Details: OPP bag + carton box
Delivery Time: 2-7 working days ( depends on your quantity )
Payment Terms: T/T, Western Union, MoneyGram, paypal
Supply Ability: 12000 pcs per day

3 Meters SC - SC Multimode Fiber Optic Cable Patch Cord Duplex With Clip OM4 cable

Description
Product Name: 3 Meters SC - SC Multimode Fiber Optic Cable Patch Cord Duplex With Clip OM4 Cable Fiber Type: OM4
Mode: Multimode Core Type: Duplex
Cable Length: Can Be Customized Packing: OPP Bag + Carton Box
Jacket Material: PVC / LSZH OEM/ODM: Acceptable
Connector: SC Application: FTTH/Test Equipments/TV/LAN/Telecommunication Equipments
Return Loss: ≥45dB Insertion Loss: ≤0.3dB
Quality Control: 100% Test Before Shipping
High Light:

duplex fiber patch cord

,

single mode fiber optic cable

Optical Fiber Patch Cord Name



3 Meters SC-SC Multimode Optical Fiber Cable Patch Cord Duplex With Clip OM4 Cable



Optical Fiber Patch Cord Description



SC connector is a square type of connector. It is bigger than LC connector. The SC connector has 0.9mm, 2.0mm, 3.0mm diameter. The connector housing is the same size, only the boot diameter is different due to the cable diameter request.



If the cable diameter is 0.9mm, but use 3.0mm diameter boot, the boot can't protect the cable from transportation, cable distribution, and shaking. That's why different cable diameters will use different diameter boot for the connector.

  • Custom Information
    new light  offers custom-made pigtails with a wide variety of options:
    a. “Unjacketed” fiber pigtails usually installed inside the ODF unit.
    b. Multi-Strand fiber pigtails without a jacket are ideal for fusion splicing.
    c. Multi-Strand fiber pigtails with fan-out are designed for patch panels or cable ducts where space-saving is required.
    d. 2, 4, 6, 8, 12, 24 and 48 Strand fiber counts available.
    Note: All pigtails can be customized in any fiber type, length, connectors and fiber counts for your requirement.

Optical Fiber Patch Cord Specifications



Product name 3 Meters SC-SC Multimode Fiber Optic Cable Patch Cord Duplex With Clip OM4 cable
Fiber Type SM(G.652/G.657A) MM(OM1/OM2/OM3/OM4/OM5)
Jacket Materials LSZH/PVC
Connector Type SC/FC/LC/ST/MTRJ/MU/MPO/MTP
Ferrule Materials Ceramic
Cable dimension 0.9mm , 2.0mm, 3.0mm
Cable color Yellow Orange, Aqua , magenta
Testing Wavelengths 1310±30/1550±30nm 850±30/1300±30nm
Insertion Loss(dB) ≤ 0.3dB
Return Loss(dB) ≥50dB
Cable Assemblies Pigtail/Simplex/Duplex/Fan-out Patchcord
Operating Temperature (° C) -10~ + 70
Storage Temperature (° C) -40 ~ +85
Package Polybag


Optical Fiber Patch Cord  Function and features



Low insertion loss

Good reproducibility

High return loss

Good mutual insert performance

Good temperature stability


Optical Fiber Patch Cord  Applications

  • CATV;
  • Active device termination;
  • Telecommunication networks;
  • Metro;
  • Local Area Networks;
  • Data processing networks;
  • Test equipment;
  • Premise installation;
  • Wide Area Networks
connector type SC, ST, FC, LC, MU, MTRJ, E2000 ,MPO/MTP,SMA....
Cables PVC/LSZH ,OM1,OM2,OM3,OM4, Plenum(OFNP) , Armored
Color yellow,gray,sky bule ,orange,white,black...



FQA :



1. Q : Are you a manufacturer ?

A: yes, we are a manufacturer in Shenzhen, China



2. Q : What's your MOQ ?

A: MOQ can be 1 pcs, but we do not suggest to order 1 pcs because the cost will be higher, so that the price will be higher than your budget.



3. Q: What's the price?

A: The price is according to your quantity. After you let us know your quantity, we will offer our best price for you. Big Quantities will get very competitive price.



4. Q: Can you quote FOB price ?

A: yes we can, but due to the size and weight is not big, most are delivery by air, DHL, TNT, UPC, FEDEX, etc. So it difficult to do FOB price. The best way is to let us know your detailed specifications and quantity, we will offer the freight with products price for your reference.



We have a very competitive price logist . If your quantity is big and there are dozens of carton boxes, we can figure out freight by sea for your reference.



EXW price or CFR price will be better . You can contact us for more solution if you need.



5. Q: How is your quality?

A: Our production is according to IEC , Europe standard production, almost closed to the dust-free workshop. Imported production equipment and quality control equipment . Especially MTP Daisi equipment.



All the products are 100% test before delivery.



6. Q: What's your lead time?

A: We have three factories in China. One factory for fiber optic cable production, two factories for patch cord, PLC, ODF, adaptor, attenuators , etc .

For fiber optic patch cord, the lead time can be 2 -3 working days for 5000 pcs. regular products we have in stock. We can deal with urgent orders for you. For more information, you can feel free to contact us.



7. Q: What's your warranty?

A: for patch cord, we have 2 years warranty since delivery, but only responsible for non-artificial damage. For artificial damage, we can repair it for you for free, but freight will be paid by your side.



8. Q : What's your packing?

A: We are using an international export package. attached some packing of different products for your reference. We also can print your logo on the packing



9. Q: Can you do OEM/ODM?

A: yes, we can. We are a manufacturer, all products accept OEM /OD M. we can sign the Confidentiality Agreement.



10. Q: Can I have a sample?

A: It depends on which products, for adaptor, attenuator, patch cord, pigtail, we can provide a sample for you for free. But freight repaid by your side.

For big value products, we can't offer it for free, sample charge and freight repaid first after you placed an order, the sample charge will be returned.



11. Q: How can I order?

A: 1. send mail to us or send inquiry. let us know the product name, detailed specifications, quantity. Provide your receive address if you need us to figure out freight for you.

2. After we know your requirements, we will offer our best price for you, with lead time. The price is according to your quantity.

3. When you accept the quotation, we will make a Proforma Invoice with our bank account.

4. We will arrange the production for you after we received the payment.

5. Before we delivery will confirm the receive information with you again .and will send the tracking number to you after delivery.

6. We will try our best to meet your requirements for long-term cooperation.



12. Q: What your payment term?

A: T/T, Western Union, Paypal, MoneyGram at once. For big amounts, can 50% deposit in advance, 50% balance paid before delivery.



Packing reference

3 Meters SC - SC Multimode Fiber Optic Cable Patch Cord Duplex With Clip OM4 cable 0
