12 Fibers Fan Out MTP MPO Cable OM3 / OM4 For Interconnect Cassettes

    • 12 Fibers Fan Out MTP MPO Cable  OM3 / OM4 For Interconnect Cassettes
    • 12 Fibers Fan Out MTP MPO Cable  OM3 / OM4 For Interconnect Cassettes
    • 12 Fibers Fan Out MTP MPO Cable  OM3 / OM4 For Interconnect Cassettes
    • 12 Fibers Fan Out MTP MPO Cable  OM3 / OM4 For Interconnect Cassettes
  • 12 Fibers Fan Out MTP MPO Cable  OM3 / OM4 For Interconnect Cassettes

    Product Details:

    Place of Origin: Shenzhen, China
    Brand Name: New Light
    Certification: CE , ISO , RoHS
    Model Number: MPO MTP

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pcs
    Price: can be negotiated
    Packaging Details: OPP bag + Carton box
    Payment Terms: L/C, T/T, Western Union, MoneyGram , Paypal
    Supply Ability: 500 pcs per day
    Contact Now
    Detailed Product Description
    Material: PVC / LSZH Connector Type: MPO / MTP Male And Female
    Mode: Single / Multi Mode Delivery Time: 2-7 Days After Receive Payment
    Production: 500 Pcs Per Day Length: As Your Requirement
    Shipping Term: By Sea Or By Air Fiber Cord: 8 Core / 12 Core / 32 Core
    Products Name: MTP MPO Cable OM3 / OM4 12 Fibers Fan Out MPO Male / Femal Connector



    MTP MPO cable OM3 / OM4 12 fibers Fan Out MPO male / femal connector



    Product Description:



    Data Transmission 12 Core MPO to LC Fan Out Patch Cord. MPO/MTP trunk cables are used to interconnect cassettes, panels or ruggedized MPO fan-outs, spanning MDA, HAD and EDA zones, and easy to rapid deployment of high density backbone cabling in data centers and other high fiber environments reducing network installation or reconfiguration.



    MPO/MPT trunk cables using a compact and rugged microcable structure, according to different colors divided into SM, MM and 10G MM. The fiber ranges from 12 to 144, MTP polarity options are TIA way is Style A(up), Style B(down) and Style C(up/up).





    Technical Data:



    MPO Series MM Standard MM Super Low Loss SM Standard MM Super Low Loss



    Insertion Loss

    Typical

    (all fibers)

    0.20dB Typical
    (all fibers)
    0.08dB

    Typical

    (all fibers)

    0.25dB Typical (all fibers) 0.10dB
    Maximum
    (singlefiber)
    0.40dB Maximum
    (single fiber)
    0.25dB Maximum
    (single fiber)
    0.75dB Maximum
    (single fiber)
    0.35dB
    Return Loss

    ≥25dB

    (Flat Polish)

    ≥25dB

    (Flat Polish)

    ≥60dB

    (8° Angle Polish)

    ≥60dB

    (8° Angle Polish)

    Durability

    ≤0.2dB change,

    1000 matings

    ≤0.2dB change,

    1000 matings

    ≤0.3dB change,

    500 matings

    ≤0.3dB change,

    500 matings

    Operating Temp. -40ºC to +75ºC
    Ferrules 4, 8, 12, 24 8, 12 4, 8, 12, 24 8, 12
    Cable Color (Standard) SM=Yellow

    OM1, OM2=Orange,

    OM3, OM4=Aqua












    Fiber Cable Performance

    Fiber Type OS2, OM1, OM2, OM3, OM4
    Fiber Count 12,24,48,72,96,144 cores
    Fiber Attenuation dB (OS2) ≤0.38 Max ≤0.34Typ(1310nm) ≤0.25 Max ≤0.19Typ(1550nm)
    Fiber Attenuation dB (OM1) ≤3.5 Max ≤2.7Typ(850nm) ≤1.5Max ≤1.2Typ(1300nm)
    Fiber Attenuation dB (OM2) ≤3.5 Max ≤2.7Typ(850nm) ≤1.5Max ≤0.9Typ(1300nm)
    Fiber Attenuation dB (OM3) ≤3.5 Max ≤2.7Typ(850nm) ≤1.5Max ≤0.9Typ(1300nm)
    Fiber Attenuation dB (OM4) ≤3.5 Max ≤2.7Typ(850nm) ≤1.5Max ≤0.9Typ(1300nm)



    Min.Bandwidth:Overfilled Launch[Mhz-km]

    OM1≥200(850nm) ≥500(1300nm) OM2≥500(850nm) ≥500(1300nm) OM3≥1500(850nm) ≥500(1300nm)OM4≥3500(850nm) ≥500(1300nm)
    Min.Bandwidth:Laser Effective Modal Bandwidth [Mhz-km] OM3 ≥2000(850nm) OM4 ≥4700(850nm)
    Outer diameter 12fiber:3.0 or 5.5mm ; 24fiber:3.0 or 5.5mm

    Outer jacket Colour



    OS2(Yellow),OM2(Orange),OM3(Aqua),OM4(Purple or Aqua) -
    Outer jacket material LSZH,OFNP,OFNR
    Tensile strength >500N
    Operating Temperature -40 ~ +85°C









    Ordering Information:







    Packing & Labeling





    The package will be packed according to standard export requirements, customer satisfication is our target.
    Label printing : Customer logo or our brand are available
    Inner packing: 5pcs in one carton
    Outer packing: the carton will be packed with sack, well protect carton from dust and wet.
    The transportation: By air ,by sea ,by DHL ,Fedex TNT ,UPS ...
