Product Details:
|
| Description: | LC Connector, Tx1550nm, DFB, Singlemode | Components: | 1.25G 20km SFP Transceiver |
|---|---|---|---|
| Power Supply: | +3.3V | Size: | 110*40*20mm |
| Use: | Optical Transmission Network | Shipment: | DHL,Fedex,UPS,TNT,EMS |
| Working Temperature: | 0℃～ +70℃ | Package Style: | SFP |
| High Light: | DHL Supported Fiber Optic Transceiver,1.25G Fiber Optic Transceiver |
||
The LC DDM feature allows for real-time monitoring of the optical signal strength, making it easier to maintain the network. The single mode capability ensures that the signal travels farther and with less attenuation, delivering high-quality transmission over longer distances. And with the LC connector, installation and maintenance are streamlined and hassle-free.
The Fiber Optic Transceiver comes in a compact SFP package style, making it easy to integrate into existing networks. Its 40km transmission range and Tx1550nm wavelength make it a reliable choice for long-distance transmission. And with its DDM support, monitoring and troubleshooting the network becomes a much simpler task.
Overall, the Fiber Optic Transceiver is a reliable and efficient choice for any optical transmission network. Its LC DDM support, single mode capability, and LC connector make it a hassle-free solution for long-distance transmission. And with its SFP package style, it's easy to integrate into any network.
| Parameter | Symbol | Min | Typ | Max | Unit | Ref. |
| Transmitter | ||||||
| Output Opt. Pwr (End of Life) | POUT | -2 | 3 | dBm | 1 | |
| Optical Wavelength | λ | 1270 | 1310 | 1360 | nm | |
| Wavelength Temperature Dependence | 0.08 | 0.125 | nm/°C | |||
| Spectral Width (-20dB) | σ | 3.0 | nm | |||
| Optical Extinction Ratio | ER | 10 | dB | |||
| Sidemode Suppression ratio | SSRmin | 30 | dB | |||
| Optical Rise/Fall Time | tr/ tf | 100 | 160 | ps | ||
| RIN | RIN | -120 | dB/Hz | |||
| Transmitter Jitter (peak to peak) | 100 | ps | ||||
| Receiver | ||||||
| Average Rx Sensitivity @ Gigabit Ethernet | RSENS3 | -25.0 | dBm | 2 | ||
| Maximum Input Power | PMAX | -3.0 | dBm | |||
| Optical Center Wavelength | λC | 1260 | 1310 | 1620 | nm | |
| LOS De -Assert | LOSD | -26 | dBm | |||
| LOS Assert | LOSA | -40 | dBm | |||
| LOS Hysteresis | 1.0 | dB | ||||
| Receiver Jitter Generation @1.25Gbps | 160 | ps | 3 |
The NEW LIGHT NLM-GE00-SFP Fiber Optic Transceiver is a high-quality product that is made in China. It contains a 1.25G 60km SFP Transceiver, which makes it perfect for optical transmission networks. The LC interface ensures that it is easy to connect and use.
The Fiber Optic Transceiver is perfect for use in areas that range from 90-120㎡, making it ideal for small to medium-sized businesses. It is a versatile product that can be used in various applications, such as data centers, LAN, WAN, and SAN. The 1310 wavelength ensures that it is reliable and provides excellent performance.
The NEW LIGHT NLM-GE00-SFP Fiber Optic Transceiver is an excellent choice for companies that require a reliable and high-performance product. It comes with a 1-year warranty, which means that customers can rest assured that they are getting a quality product.
The product is shipped through reliable shipping partners such as DHL, FedEx, UPS, TNT, and EMS, ensuring that customers get their products in a timely and efficient manner.
In conclusion, the NEW LIGHT NLM-GE00-SFP Fiber Optic Transceiver is an excellent product that is perfect for small to medium-sized businesses. It is easy to use, reliable, and provides excellent performance. With its 1.25G SFP and LC interface, it is a versatile product that can be used in various applications. The 1310 wavelength ensures that it is reliable and provides excellent performance.
Product Packaging and Shipping:
Our Fiber Optic Transceiver product comes in a sturdy cardboard box designed to protect it during shipping. Inside the box, you will find the transceiver unit, along with any necessary cables and mounting hardware.
We take great care in packaging and shipping our products to ensure they arrive in excellent condition. All orders are shipped within 1-2 business days of purchase and are sent via a reliable shipping service.
If you have any questions or concerns about the packaging or shipping of our Fiber Optic Transceiver product, please don't hesitate to contact us.
Q: What is the brand name of the Fiber Optic Transceiver?
A: The brand name of the Fiber Optic Transceiver is NEW LIGHT.
Q: What is the model number of the Fiber Optic Transceiver?
A: The model number of the Fiber Optic Transceiver is NLM-GE00-SFP.
Q: Where is the Fiber Optic Transceiver manufactured?
A: The Fiber Optic Transceiver is manufactured in China.
Q: What is the data transfer rate of the Fiber Optic Transceiver?
A: The Fiber Optic Transceiver supports data transfer rates of up to 1Gbps.
Q: Is the Fiber Optic Transceiver compatible with different modes of fiber optic cables?
A: Yes, the Fiber Optic Transceiver is compatible with both single mode and multi-mode fiber optic cables.
