Product Details:
|
| Name: | Fiber Optic Ceramic Ferrule | Color: | White |
|---|---|---|---|
| Material: | Ceramic | Connector Type: | SC |
| Polish: | APC | OEM: | Available |
| High Light: | fiber optic parts and accessories,fiber optic cable assembly |
||
CATV Fiber Optic Cable Assembly , Fiber Optic Accessories SC / APC Step Ferrule
Applications
• CATV
• Telecom network
• Optical test equipment
• Local area networks
• Wide area networks
• Data processing Networks
Features
• Excellent materials
• Good compatibility
• Good reliability and stability
• Precise dimension
• Low insertion loss, and high return loss
• High intensity, good anti-erosion and anti-aging performance
Specifications
| Item | SC/PC Series | SC/APC Series | LC/MU Series |
| Length | 10.50±0.01mm | 10.50±0.01mm | 6.50±0.01mm |
| Outer-diameter | 2.4990±0.0005mm | 2.4990±0.0005mm | 1.4990±0.0005mm |
| Inner-diameter | 0.125~0.128mm | 0.125~0.126mm | 0.125~0.128mm |
| Concentricity | ≤1um, ≤3um | ≤0.5um, ≤1um | ≤1um, ≤3um |
| Endface Type | Spherical Surface | Step or Conical | Spherical Surface |
