Industrial 12 Core OM4 LSZH MPO MTP Cable for High-Speed Ethernet Networks

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

Industrial 12 Core OM4 LSZH MPO MTP Cable for High-Speed Ethernet Networks

Brand Name:	New Light
Model Number:	MPO / MTP - MPO / MTP
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Name:

MPO MTP Cable

Material:

LSZH, OFNP Or OFNR

Mode Type:

Core Type:

12 Core

Delivery Time:

2-7 Working Days After Received Deposit

Production Ability:

500 Pcs / Day

Payment Term:

T/T , 30% Deposit In Advance

Connector:

MPO,MTP

Color:

Aqua,orange,yellow,Yellow/ Red/ Aqua

Supply Ability:

500 pcs per day

Highlight:

mpo fiber cable

mpo to mpo cable

Product Description

Industrial Multi Fiber Cable With MTP/MPO Connectors

Multi-fiber cables with MTP/MPO connectors contain 12 or 24 fibers and are engineered for high-density, high-speed Ethernet networks. These cables optimize space and reduce costs in data centers where simultaneous multi-fiber transmission is required. A single MTP/MPO cable replaces up to 12 or 24 individual fiber cables in equipment racks, enabling easier installations. Common applications include 10 Gbps, 40 Gbps, and 100 Gbps network connectivity.

MPO Polarity

The ANSI/TIA 568-3.D standard defines three pinning methods for multi-fiber array systems: Method A, B, and C. While no single method is preferred, the standard recommends selecting one method and maintaining consistency throughout your installation. Three connectivity methods—A, B, and C—mirror the cable types to ensure proper polarity, with each handling the transmit-to-receive transition differently.

Method A (Straight-through): Most commonly used approach with pin 1 to pin 1 connectivity using Method A (key-up to key-down) MPO connectors
Method B (Crossover): Features pin 1 to pin 12 connectivity using Method B (key-up to key-up) MPO connectors
Method C (Flipped pairs): Uses pin 1 to pin 2 connectivity with Method A (key-up to key-down) MPO connectors (no migration pathway to 40-/100-GbE)

MPO MTP Cable Features

US Conec MTP connector, Senko MPO Plus premium connector
OS2, OM3, OM4 fiber grades (OM1 and OM2 available)
0.35dB Elite low loss MTP/MPO connector as well as standard versions of 0.6/0.75dB
Factory terminated and tested
Allow easy migration from 10GbE to 40GbE or 100GbE
Pulling eyes available as optional protection for fiber ends during installation

MPO MTP Cable Technical Parameters

Item	Technical Parameters
Connector	MPO/MTP (F or M)
Operation Temperature	-40°C ~ +80°C
Storage Temperature	-40°C ~ +85°C
Insertion Loss	SM: ≤ 0.75dB (standard), ≤0.35dB (typical); MM: ≤ 0.50dB (standard), ≤0.35dB (typical)
Return Loss	SM: ≥60dB; MM: ≥35dB
MPO End Type	Male: with guide pin; Female: without guide pin
Fiber Count	8, 12 & 24 fiber
Connector Type of Other End	MPO-female, MPO-male, FC, SC, ST, MU, LC, E2000
Fiber Mode	Single-mode (G652, G655, G657), multi-mode (50, 62.5, OM2, OM3, OM4)
Fiber Cable Type	250um ribbon fiber, ribbon cable, Bundle fiber optic cable

The three polarity methods Type A, Type B and Type C guarantee proper bi-directional allocation.

Packaging

Products are packaged in OPP bags with carton boxes for external protection to prevent damage during delivery.

Contact: WHATSAPP +8613534063703

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer located in Shenzhen, China.

What's your MOQ?

MOQ can be 1 piece, but we don't recommend ordering single units as costs and prices will be higher than your budget.

What's the price?

Pricing depends on quantity. We provide our best pricing after receiving your quantity requirements, with competitive pricing for larger orders.

Can you quote FOB price?

Yes, but due to small size and weight, most deliveries are by air (DHL, TNT, UPC, FEDEX). EXW price or CFR price is typically better. Contact us for freight solutions based on your specifications and quantity.

How is your quality?

Production follows IEC and European standards in near dust-free workshops with imported production and quality control equipment. All products are 100% tested before delivery.

What's your lead time?

We operate three factories in China. For fiber optic patch cords, lead time is 2-3 working days for 5000 pieces. Regular products are in stock, and we accommodate urgent orders.

What's your warranty?

Patch cords carry a 2-year warranty from delivery for non-artificial damage. For artificial damage, we provide free repairs with freight paid by customer.

What's your packing?

We use international export packaging and can print your logo on packaging upon request.

Can you do OEM/ODM?

Yes, we accept OEM/ODM and can sign confidentiality agreements.

Can I have a sample?

Free samples available for adaptors, attenuators, patch cords, and pigtails with freight prepaid by customer. Higher-value products require sample charge and freight prepayment, refundable upon order placement.

How can I order?

Send inquiry with product name, specifications, quantity, and delivery address
We provide best pricing and lead time based on your requirements
Upon acceptance, we issue Proforma Invoice with bank account details
Production begins after payment receipt
We confirm delivery information and provide tracking number
We prioritize long-term cooperation and customer requirements

What are your payment terms?

T/T, Western Union, Paypal, MoneyGram. For large amounts: 50% deposit in advance, 50% balance before delivery.
