24 Port 1U Black Standard Size Fiber Optic Patch Panel with Slide-Out Drawer Enclosure

Brand Name: New light
Model Number: 12/ 24 /48 core ptach panel
MOQ: 1~10000
Price: 10~100
Packaging Details: opp bag+Carton box
Payment Terms: T/T,Western Union,MoneyGram,Paypal
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ROHS ;ISO9001
Aplication:
Data Centers,pre-terminated Installations
Front Panel:
LC , SC , ST , FC , E2000
Product Name:
24 Fiber Rack Mounted MPO/MTP Fiber Optic Patch Panel
Tray:
12/24/48/72/96 Fiber
Weight:
6kg
Material:
Phosphor Bronze
Color:
White
Storage Temperature:
-45°C~+60°C
Product Type:
Slide-out Drawer Enclosure With Splice Trays
Dimensions:
1.75"H X 17.0"W X 14.0"D,485mmx294mmx44mm
Adapter Type:
ST
Port:
12/24/36/48/72/96/144/192/288/386
Supply Ability:
10000 per day
Highlight:

fiber optic parts and accessories

,

fiber optic accessories

Product Description
LC/SC/ST/FC Patch Panel Fiber Optic 24 Port 1U Black Standard Size
1U black standard size LC/SC/ST/FC patch panel fiber optic 24 port
Product Overview
This 1U black standard size LC/SC/ST/FC patch panel fiber optic 24 port includes MPO/MTP cable and adapters, also known as fiber distribution panels. They facilitate easy termination of fiber optic cables and provide access to individual fibers for cross connection.
A basic fiber optic panel is typically a metal enclosure that houses adapter panels and fiber splice trays. Splice trays allow fibers to be fused together with fiber optic pigtails, which are then plugged into the fixed inside ports of the adapter panels.
The inside ports of the panel are usually fixed, meaning cables remain permanently connected. The outside ports are reserved for fiber patch cables that can be frequently plugged and unplugged to arrange connections between devices as needed.
Fiber patch panels feature two compartments: one contains bulkhead receptacles or adapters, and the other is used for splice tray and excess fiber storage.
24 Port 1U Black Standard Size Fiber Optic Patch Panel with Slide-Out Drawer Enclosure 0
Available as slide-out rack mount fiber optic enclosures, loaded with various adapter configurations including 3 pieces of LC multimode duplex adaptor and splice tray, or 6 pieces of ST singlemode adaptor and splice tray.
Different models accommodate 12 core fiber, 24 core fiber, 36 core fiber, 48 core fiber, 72 core fiber, 96 core fiber, and 144 core fiber applications. Compatible with various adapter interfaces including SC, ST, FC, LC, MTRJ, and e2000. Related fiber accessories and pigtails are optional.
Applications
  • Telecommunications subscriber loop
  • Fiber to the home (FTTH)
  • LAN/WAN networks
  • CATV systems
Key Features
  • Used for branch connection of optical cable termination
  • 19" Standard Structure, Rack mounting compatible
  • Available for installation of various adaptors
  • Drawer Structure for easy operation
  • Compact design for space saving
  • Easy management and operation
  • Standard size, light weight and reasonable structure
Mechanical and Environmental Characteristics
Parameter Specification
Operating temperature -25℃ to +40℃
Storage temperature -25℃ to +55℃
Relative humidity ≤85% (+30℃)
Air pressure 70Kpa to 106Kpa
Color Black
Dimensions
Model Fiber Quantity Height Dimension (LxWxH)
Rack mount 12/24/48/96 core 1U 430*354.1*44mm
Polarity Methods
Method A
Uses Type A straight-through MPO trunk cables with a key up connector on one end and key down connector on the other end, ensuring fiber in Position 1 arrives at Position 1 at the opposite end. For duplex applications, requires a transceiver-receiver flip in a patch cord at one end.
Method B
Uses key up connectors on both ends to achieve transceiver-receiver flip, where fiber in Position 1 arrives at Position 12 at the opposite end, Position 2 arrives at Position 11, and so on. For duplex applications, uses straight A-B patch cords on both ends.
Method C
Uses key up connector on one end and key down on the other end like Method A, but with fiber pairs flipped within the cable itself. While suitable for duplex applications, this method does not support parallel 8-fiber 40 and 100 Gig applications and is not recommended.
Fluke Networks' MultiFiber™ Pro allows users to test individual patch cords, permanent links and channels for correct polarity, helping prevent deployment mistakes.
24 Port 1U Black Standard Size Fiber Optic Patch Panel with Slide-Out Drawer Enclosure 1
