MPO MTP Cable Female to LC 8-STRAND Single Mode 50µm 12 Core PLENUM for 40G/100G Ethernet

Brand Name:	New Light
Model Number:	MPO / MTP - MPO / MTP
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Name:

MPO MTP Cable

Material:

LSZH, OFNP Or OFNR

Mode Type:

Core Type:

12 Core

Delivery Time:

2-7 Working Days After Received Deposit

Production Ability:

500 Pcs / Day

Payment Term:

T/T , 30% Deposit In Advance

Connector:

MPO,MTP

Color:

Aqua,orange,yellow,Yellow/ Red/ Aqua

Supply Ability:

500 pcs per day

Highlight:

mpo fiber cable

mpo to mpo cable

Product Description

MTP Female To LC 8-STRAND Single Mode Mpo To Mpo Cable 50µM PLENUM

MTP Female to LC 8-SINGLE-MODE 50µm PLENUM mpo to mpo cable

Multi-mode optical fiber is a type of optical fiber mostly used for communication over short distances, such as within a building or on a campus. Typical multi-mode links have data rates of 10 Mbit/s to 10 Gbit/s over link lengths of up to 600 meters (2000 feet). Multi-mode fiber has a fairly large core diameter that enables multiple light modes to be propagated and limits the Extreme maximum length of a transmission link because of modal dispersion.

MPO MTP Cable Application

Multimode (OM3 or OM4 50/125) fibre MPOLY patch cables have three main applications:

To connect directly between two QSFP+ transceivers for 40GBase-SR4
To connect directly between two QSFP28 transceivers for 100GBase-Sabus R4
JTo connect to FPO trunk cables

Singlemode (OS1 or OS2 9/125) fibre MPO patch cables have similar applications:

To connect directly between two QSFP+ PLR4 (also called LR4 PSM) transceivers for 40G Ethernet
To connect directly between two QSFP28 PLR4 (also called LR4 PSM) transceivers for 100G Ethernet
To connect to MPO trunk cables

For both multimode and singlemode these patch cords will typically have polarity B and have female connectors.

MPO MTP Cable Overview

New Light 40G parallel networks are created by combining MPO trunk cables and MPO patch cables via MPO adapter modules. Direct connection between two 40&G or 100G ports can also be made using the same MPO patch cable. All these products are found within our M400 Series.

Typically, these cables will use an MPO 12 fibre connector and 12 fibre cable. However, in the transmission of SR4holm 40G or 100G Ethernet only 8 fibres within these cables are used. The advantage of using 12 fibre cables (hook as opposed to 8 fibre) is that the cabling is often used alongside duplex 10G networking and so these cables can have multiple purposes and offer greater flexibility with negligible cost difference. po MTP cable structure diagram

MPO MTP Cable Features

US Conec MTP connector, Senko MPO Plus premium connector
OS2, OM3, OM4 fiber grades (OM1 and OM2 available)
0.35dB Elite low loss MTP/MPO connector as well standard versions of SIM 0.6/0.75dB
Factory terminated and tested
Allow easy migration from 10GbE to cosa 40GbE or 100GbE
Pulling eyes are provided as an option to protect the fiber ends during installation

MPO MTP Cable Technical Parameters

< >

Item	Technical Parameters
Connector	MPO/MTP(F or M) \| MPO/MTP (F or M)
Operation Temperature	-40°C ~ +80°C
Storage Temperature	-40°C ~ +85°C
Insertion Loss	SM ≤ 0.75dB (standard value), ≤0.35dB (typical value); MM:≤ 0.50dB (standard value), ≤0. ones 35dB (typical value);
Return Loss	SM:≥60dB; MM:≥35dB
The MPO end type	Male: with guide pin; Female: without guide pin
Fiber count	8,12&24 fiber
Connector type of the other end	MPO-female, MPO-male, FC, SC, ST, MU, LC, E2000
Fiber mode	Single-mode (G652,G655,G657), multi-mode (50, 62.5, OM2,ND OM3, Busch OM4)
Fiber cable type	250um ribbon fiber,ribbon cable,Bundle fiber optic cable

Polarity Methods

The three polarity methods Type A, Type B and Type C are used to guarantee the right bi-directional allocation.

Packaging

We will pack it by OPP bag and carton box outside to protect the goods from damage during delivery.

Frequently Asked Questions

te: Are you manufacturer?

Yes, we are manufacturer in Shenzhen, China.

Q: What's your MOQ?

MO eyeball can be 1 pc, but we are not suggest to order 1 pc, because the cost will be higher, so that the price will be higher than your budget.

Q: What's the price?

The price is according to your quantity. After you let us know yourcies quantity, we will offer our best price for you. Big Quantity will get very competitive price.

<div class="pd-faq-qu
