12 Core MPO MTP Cable with LSZH Material and Low Insertion Loss for 40G/100G Ethernet

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

12 Core MPO MTP Cable with LSZH Material and Low Insertion Loss for 40G/100G Ethernet

Brand Name:	New Light
Model Number:	MPO / MTP - MPO / MTP
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Name:

MPO MTP Cable

Material:

LSZH, OFNP Or OFNR

Mode Type:

Core Type:

12 Core

Delivery Time:

2-7 Working Days After Received Deposit

Production Ability:

500 Pcs / Day

Payment Term:

T/T , 30% Deposit In Advance

Connector:

MPO,MTP

Color:

Aqua,orange,yellow,Yellow/ Red/ Aqua

Supply Ability:

500 pcs per day

Highlight:

mpo fiber cable

mpo to mpo cable

Product Description

12 MTP Fiber Cable, Multimode OM1 OM2 OM3 OM4 OS2 MPO - MPO Connectors

Product Description

The MTP connector features benefits not available on generic MPO connectors, including a removable housing that allows re-working and re-polishing of the MT ferrule, gender change after assembly or in the field, and interferometric scanning after assembly. The MTP connector includes a floating ferrule for improved mechanical performance, stainless steel elliptical guide pin tips, and a metal pin clamp with push spring centering features. Its spring design maximizes ribbon clearance for twelve fiber and multi-fiber ribbon applications to prevent fiber damage. Available with four strain relief boot variations to suit diverse applications.

MPO MTP Cable Applications

Multimode (OM3 or OM4 50/125) fiber MPO patch cables applications:

Connecting directly between two QSFP+ transceivers for 40GBase-SR4
Connecting directly between two QSFP28 transceivers for 100GBase-SR4
Connecting to MPO trunk cables

Singlemode (OS1 or OS2 9/125) fiber MPO patch cables applications:

Connecting directly between two QSFP+ PLR4 (LR4 PSM) transceivers for 40G Ethernet
Connecting directly between two QSFP28 PLR4 (LR4 PSM) transceivers for 100G Ethernet
Connecting to MPO trunk cables

MPO MTP Cable Features

US Conec MTP connector, Senko MPO Plus premium connector
OS2, OM3, OM4 fiber grades (OM1 and OM2 available)
0.35dB Elite low loss MTP/MPO connector as well standard versions of 0.6/0.75dB
Factory terminated and tested
Easy migration from 10GbE to 40GbE or 100GbE
Optional pulling eyes to protect fiber ends during installation

MPO MTP Cable Technical Parameters

Item	Technical Parameters
Connector	MPO/MTP(F or M)
Operation Temperature	-40°C ~ +80°C
Storage Temperature	-40°C ~ +85°C
Insertion Loss	SM: ≤ 0.75dB (standard), ≤0.35dB (typical); MM:≤ 0.50dB (standard), ≤0.35dB (typical)
Return Loss	SM:≥60dB; MM:≥35dB
The MPO end type	Male: with guide pin; Female: without guide pin
Fiber count	8,12&24 fiber
Connector type of the other end	MPO-female, MPO-male, FC, SC, ST, MU, LC, E2000
Fiber mode	Single-mode (G652,G655,G657), multi-mode (50, 62.5, OM2, OM3, OM4)
Fiber cable type	250um ribbon fiber, ribbon cable, Bundle fiber optic cable

The three polarity methods Type A, Type B and Type C are used to guarantee the right bi-directional allocation.

Packaging

Products are packed in OPP bags and carton boxes to prevent damage during delivery.

Frequently Asked Questions

1. Are you manufacturer?

Yes, we are manufacturer in Shenzhen, China.

2. What's your MOQ?

MOQ can be 1 pc, but we don't recommend ordering just 1 pc as the cost will be higher.

3. What's the price?

Price depends on quantity. We'll offer our best price after receiving your quantity requirements.

4. Can you quote FOB price?

Yes, but most deliveries are by air (DHL, TNT, UPC, FEDEX). For large quantities, we can provide sea freight options.

5. How is your quality?

Our production follows IEC and European standards, with imported equipment and 100% testing before delivery.

6. What's your lead time?

2-3 working days for 5000 pcs. Regular products are in stock and urgent orders can be accommodated.

7. What's your warranty?

2 years warranty for patch cords (non-artificial damage). Artificial damage can be repaired for free (customer pays freight).

8. What's your packing?

International export packaging with optional logo printing available.

9. Can you do OEM/ODM?

Yes, we accept OEM/ODM and can sign confidentiality agreements.

10. Can I have a sample?

Free samples available for some products (customer pays freight). High-value products require sample charge.

11. How can I order?

Send inquiry with product details and quantity
We'll provide best price and lead time
Proforma invoice sent after acceptance
Production begins after payment
Shipping confirmation with tracking number

12. What's your payment term?

T/T, Western Union, Paypal, MoneyGram. For large amounts: 50% deposit, 50% before delivery.
