Product Details:
|
| Name: | LC/APC Adapter Without Flange | Color: | Green |
|---|---|---|---|
| High Light: | sc simplex adapter,lc fiber optic adapter |
||
FTTH / Data Center Fiber Optic Adaptor LC / APC Duplex without Flange
Quick Detail:
1. LC duplex adapter
2. With flange for screws
3. Singlemode PC, singlemode APC and multimode PC available
Description:
FOCONEC offers Simplex, duplex & quad LC adapters with plastic housing. All LC duplex & quad adaptors have more options, with or without flanges, and in SC-footprint or Square mount styles.
All our adaptors come with a choice of zirconia or phosphor bronze straight split sleeves. For customized requirement, the housing in a variety of colors are available.
Features:
1. High precision of mechanical dimensions
2. Excellent compatibility, reliability & stability
3. Single-mode and multimode available
4. With or without flange available
5. NTT, Telcordia, ANSI, TIA/EIA standard compliance
Order Guide:
| Product Description | Part Number | Housing Color |
| LC Duplex Single-mode With Flange | AD-LCDF-SM | Blue |
| LC/APC Duplex Single-mode With Flange | AD-LCDF-SMA | Green |
| LC Duplex Multimode With Flange | AD-LCDF-MM | Beige |
| LC Duplex OM3 With Flange | AD-LCDF-OM3 | Aqua |
Applications:
1. Fiber optic transmission system
2. CATV networks
3. Local Area Network
4. FTTH and FTTX
5. Testing equipment
Specifications:
| Connector Type | LC, SC, FC, MU, ST, MTRJ, Hybrid | |
| Fiber Type | Singlemode | Multimode |
| Insertion Loss | ≤0.2dB | |
| Return Loss | PC≤-45dB; UPC≤-50dB; APC≤-60dB | ≤-30dB |
| Durability | ≤0.2dB, after 1000 times | |
| Operation Temperature | -40℃~+75℃ | |
| Storage Temperature | -40℃~+85℃ | |
