Product Details:
|
| Application: | FTTH FTTB FTTX Network,Telecommunication,Data Center Network,MTP MPO Network | Material: | Cold- Roll Steel,Aluminum |
|---|---|---|---|
| Fiber Type: | Singlemode Or Multimode | Connector: | MPO/MTP |
| Connector Type: | MPO/LC/SC/FC/ST/MU,MPO,MTP,MPO-MPO/MPO-LC | Operating Temperature: | -40℃ ~ +80℃,40~+85 |
| Product Name: | Optical Fiber MPO Cassette | Warranty: | 3 Years |
| Wavelength: | 850nm/1310nm | Return Loss: | ≥60dB (SM) |
| Insertion Loss: | Standard Loss And Elite | ||
| High Light: | fiber optic cassette module,mtp casstte module |
||
MPO-24 to 12x LC Duplex, Type A, 24 Fibers OS2 Single Mode FHD MPO Cassette
Product description:
New Light MPO-24 to 12x LC Duplex, Type A, 24 Fibers OS2 Single Mode FHD MPO Cassette consist of pre-terminated LC or SC adapters for quick and easy deployment in high density applications and provide efficient utilization of rack space and design flexibility. The cassettes interconnect with high-density fiber cable assemblies for quick connection of remote or data center applications
FHD High Density Series is a versatile solution in multiple sizes (1U/2U/4U) and styles for building backbones, data centers and enterprise applications, 1U up to 96 LC fibers.
Product Features:
• High-density modular design, up to 96 fiber in 1U for efficient utilization.
• Pre-terminated cassette for improved reliability and quick deployment.
• High performance connectors to achieve a low loss optical budget.
• Plug-N-play modules allow fast installation of multiple fiber links.
• Offered in a wide range of performance and polarity configurations.
• The corning fiber compoliant to Telcordia, EIA/TIA and IEC standards.
Learn more ,pls link :
https://youtu.be/n0NzAOHr10s
| Fiber Count | 12 / 24 | Fiber Mode | OM3 50/125 μm |
| Front Connector Type | 12 LC UPC Duplex | Rear Connector Type | 1x MPO UPC Male (pinned) |
| MPO Adapter | Key up to Key down | Glass Fiber | Corning ClearCurve® |
| Insertion Loss | MPO≤0.35 dB, LC≤0.2 dB | Return Loss | MPO≥20 dB, LC≥30 dB |
| Operating Temperature | 0°C to 70°C | Storage Temperature | -40°C to 75°C |
| Dimensions (HxWxD) | 1.38''x4.29''x4.64'' (35x109x118 mm) | Application | Matching for Type AF Cassette |
Performance Properties:
| Front Connector | LC/SC duplex |
| Material of Sleeve | Zirconia Ceramic |
| Insertion Loss | Multimode: UPC ≤0.2dB Single mode: APC ≤0.3dB UPC ≤0.2dB |
| Return Loss | Multimode: UPC ≥30dB Single mode: APC ≥60dB UPC ≥50dB |
Polarity Illustration:
In any installation, it is important to ensure that the transmitter at one end matches the corresponding receiver at the other end. FS provides a number of intelligent solutions that can help you manage and optimize your network and its connectivity.
