| Brand Name: | New light |
| Model Number: | 6/12 port MPO |
| MOQ: | 10 pcs |
| Price: | USD 68-120 set |
| Packaging Details: | opp bag+Carton box |
| Payment Terms: | T/T, Western Union, MoneyGram ,Paypal |
MPO-8 to 4x LC Duplex, 8 Fibers OS2 Single Mode FHD MPO Cassette, 40G/100G to 10G/25G
Product description:
New Light MPO to LC/SC OS2 Single Mode FHD Fiber Optic Plug-N-Play Cassette that has a LGX footprint and allows for the break-out to 24 LC connectors. The cassette uses an angled polish LC connector with low insertion loss.
Inside the cassette is a fan out/breakout cable assembly, making use of a Corning fiber in a ribbon configuration to 24 LC connections which then couple with 24 LC patch cables on the front of the cassette, and 2 MTP/MPO 12 UPC connectors on the rear of the cassette. The cassette can be installed in either a vertical or a horizontal MPO cassette holder
FHD High Density Series is a versatile solution in multiple sizes (1U/2U/4U) and styles for building backbones, data centers and enterprise applications, 1U up to 96 LC fibers.
Product Features:
• High-density modular design, up to 96 fiber in 1U for efficient utilization.
• Pre-terminated cassette for improved reliability and quick deployment.
• High performance connectors to achieve a low loss optical budget.
• Plug-N-play modules allow fast installation of multiple fiber links.
• Offered in a wide range of performance and polarity configurations.
• The corning fiber compoliant to Telcordia, EIA/TIA and IEC standards.
Learn more ,pls link :
https://youtu.be/n0NzAOHr10s
| Fiber Count | 12 / 24 | Fiber Mode | OM3 50/125 μm |
| Front Connector Type | 12 LC UPC Duplex | Rear Connector Type | 1x MPO UPC Male (pinned) |
| MPO Adapter | Key up to Key down | Glass Fiber | Corning ClearCurve® |
| Insertion Loss | MPO≤0.35 dB, LC≤0.2 dB | Return Loss | MPO≥20 dB, LC≥30 dB |
| Operating Temperature | 0°C to 70°C | Storage Temperature | -40°C to 75°C |
| Dimensions (HxWxD) | 1.38''x4.29''x4.64'' (35x109x118 mm) | Application | Matching for Type AF Cassette |
Performance Properties:
| Front Connector | LC/SC duplex |
| Material of Sleeve | Zirconia Ceramic |
| Insertion Loss | Multimode: UPC ≤0.2dB Single mode: APC ≤0.3dB UPC ≤0.2dB |
| Return Loss | Multimode: UPC ≥30dB Single mode: APC ≥60dB UPC ≥50dB |
Polarity Illustration:
In any installation, it is important to ensure that the transmitter at one end matches the corresponding receiver at the other end. FS provides a number of intelligent solutions that can help you manage and optimize your network and its connectivity.
|
