PVC/LSZH Optical Fiber Patch Cord Lc To Lc Multimode Fiber Duplex Single Mode

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

PVC/LSZH Optical Fiber Patch Cord Lc To Lc Multimode Fiber Duplex Single Mode

Brand Name:	NewLight
Model Number:	NL001
MOQ:	1~100000
Price:	0.1~100
Packaging Details:	1 pcs per pack
Payment Terms:	T/T, Western Union, MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Connector:

LC-LC

Fiber Type:

Simplex And Duplex

Application:

FTTH FTTB FTTX Network,FTTA FTTH BBU RRU RRH LTE & Base Station,For ODF Internal Link,For Room Equipment Internal Link,FTTH/Test Equipments/TV/LAN/Telecommunication Equipments

Length:

Any Length Is Customizable

Connector Type:

SC/FC/LC/ST/MU/DIN/D4/MTRJ/MPO

Type:

Single Mode/Multi-mode

Fiber Count:

Simplex Or Duplex

Material:

PVC/LSZH

Color:

Orange Or Others,aqua Or Cusomized

Supply Ability:

1000000

Highlight:

single mode fiber optic cable

duplex fiber patch cord

Product Description

fiber patch cord lc to lc multimode fiber duplex single mode fiber optic patch cord

Description:

High Quality LC Uniboot Interconnect Tight-Buffered Patch Cable , 2 Fibers , SMF

As the networking environment of today becomes increasingly dependent on high speed and high density solutions, effective cable management is a real issue. The key concern is how to manage more cable in a smaller amount of space.

The Uniboot patch cord utilizes a special “round duplex” cable that allows duplex transmission within a single cable, and it reduces cable management space comparing to standard patch cords. The high density cables designed with flexible “push-pull tab” uniboot connector, bend insenstive fiber and ultra-low insertion loss(0.15dB) for 10GBase, 40GBase and 100GBase network connection in data center. OMC's LC Uniboot cable assemblies offer the best solution for high-density applications, Data centers, Interconnect and cross-connector, Private Networks and premise installations.

Our uniboot fiber patch cord reduces cable management space by up to 68% compared to standard patch cords. The patch cord utilizes a special “round duplex” cable that allows duplex transmission within a single 3mm cable. As a result of these features our uniboot patch cord offers improved airflow and visibility of equipment within a high density network environment. Our uniboot patch cord is available in a wide variety of cable materials including LSZH, Plenum and Riser

Ordering Options:

Both singlemode and multimode versions fiber optic patch cord come with a zirconia ceramic ferrule with pre-polished PC,UPC,APC profile and convex spherical end.

These end face types allow for faster polishing, and low back reflection and optical loss, while ensuring maximum repeatability

PVC/LSZH Optical Fiber Patch Cord Lc To Lc Multimode Fiber Duplex Single Mode 0

Connector type	SC,FC,ST,LC,E2000,DIN,MU,MTRJ,etc
Polish	UPC,APC,PC
Cable type	Simplex,Duplex straight,Duplex Reverse
Fiber	SM(G652),62.5/125um,50/125um,OM2,OM3,SM(G655)
Cable Jacket	Riser,Plenum,LSZH
Cable Diameter	3.0mm,2.0mm,0.9mm,etc
Cable Length	Length in meter

Type:

* Connector type: FC,SC,ST,LC,MT-RJ,MU,etc.

* Ferrule endface: PC,UPC,APC,etc.

* Fiber type: single mode,polarization-maintaining optical fiber,multimode 50/125,mutimode 62.5/125,etc.

* Cable diameter: 0.9mm,2.0mm,3.0mm,etc.

* Number of fiber connected: single-core connector,dual-core connector and multi-core connector.

Specification:

Fiber type	Single mode:	(1)9/125-G652D	(2)9/125-G655	(3)9/125-G657A,G657A2	(4)9/125-G657B3
	Multimode:	(5)50/125-OM2	(6)62.5/125-OM1	(7)50/125-OM3	(8)50/125-OM4	(9)50/125-OM5
Fiber Brand	YOFC, Corning, Sumitomo, Fujikura
Connector	SC/PC, SC/APC, LC/PC, LC/APC, FC/PC, FC/APC, ST/PC, E2000/PC, E2000/APC, MU/PC, MTRJ/Female, MTRJ/Male, MPO/MTP, DIN/PC, SMA/PC, D4/PC
Cord type	Simplex ,Duplex
Cable diameter	0.9mm ,1.2mm, 1.6mm, 1.8mm, 2.0mm, 2.8mm, 3.0mmm, 4.1mm
Cable jacket	PVC, OFNR, LSZH, OFNP
length(M)	0.5m,1m,2m,5m,10m,25m,50m,100m...Customized

Features

* Good durability

* Good exchangeability

* High temperature stability

* Low insertion loss and back reflection loss

* Superior quality standard PC/UPC/APC Polishing

* Standard: Telcordia GR-326-CORE,TIA/EIA and IEC

PVC/LSZH Optical Fiber Patch Cord Lc To Lc Multimode Fiber Duplex Single Mode 1
