Female OM3 12 Fibre MPO Breakout Cable with LSZH Sheath for High-Density Data Centers

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

Female OM3 12 Fibre MPO Breakout Cable with LSZH Sheath for High-Density Data Centers

Brand Name:	New Light
Model Number:	MPO / MTP - MPO / MTP
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Connector Type:

MPO / MTP TO MPO / MTP

Material:

LSZH, OFNP Or OFNR

Mode Type:

Core Type:

12 Core

Length:

Customized

Certificate:

CE , ISO , RoHS

Delivery Time:

2-7 Working Days After Received Deposit

Production Ability:

500 Pcs / Day

Payment Term:

T/T , 30% Deposit In Advance

Connector:

MPO,MTP

Color:

Multi Color

Supply Ability:

500 pcs per day

Highlight:

3.0mm MPO Breakout Cable

OM3 Mpo Patch Cord

LSZH Mtp Fiber Cable

Product Description

Female OM3 12 Fibre 3.0mm MPO Breakout Cable Single Sheath LSZH

MPO (female) OM3 (50/125) 12 fibre micro core (3.0mm) single sheath cable LSZH

MPO MTP Cable Overview

The MTP cable construction features a micro core design that is exceptionally lightweight with a small bend radius, making these cables ideal for data center applications requiring high-density fiber installations. Fiber networks utilizing MTP cables and cassettes offer simplified installation processes. Each MTP cable can connect to MTP cassettes, providing from 12 fibers (6 LC ports) up to 144 fibers (72 LC ports). This modular approach enables rapid, organized installations and allows customers to scale their fiber network infrastructure according to specific expansion requirements.

MPO MTP Cable Features

US Conec MTP connector, Senko MPO Plus premium connector
OS2, OM3, OM4 fiber grades (OM1 and OM2 available)
0.35dB Elite low loss MTP/MPO connector as well as standard versions of 0.6/0.75dB
Factory terminated and tested
Easy migration from 10GbE to 40GbE or 100GbE
Pulling eyes available as optional protection for fiber ends during installation

MPO MTP Cable Technical Parameters

Item	Technical Parameters
Connector	MPO/MTP(F or M)
Operation Temperature	-40°C ~ +80°C
Storage Temperature	-40°C ~ +85°C
Insertion Loss	SM: ≤ 0.75dB (standard), ≤0.35dB (typical); MM: ≤ 0.50dB (standard), ≤0.35dB (typical)
Return Loss	SM: ≥60dB; MM: ≥35dB
MPO End Type	Male: with guide pin; Female: without guide pin
Fiber Count	8, 12 & 24 fiber
Connector Type of Other End	MPO-female, MPO-male, FC, SC, ST, MU, LC, E2000
Fiber Mode	Single-mode (G652,G655,G657), multi-mode (50, 62.5, OM2, OM3, OM4)
Fiber Cable Type	250um ribbon fiber, ribbon cable, bundle fiber optic cable

Applications

Duplex 1G to 10G Ethernet Networks

MPO patch cables with 12-fiber connectors and cables are primarily used in distribution areas requiring high-density patching fields. Compared to standard duplex LC-LC patch cables, MPO cables increase patching density by a factor of six. Typically, these cables feature polarity C with male MPO connectors that connect to polarity C trunk/backbone MPO cables with female connectors.

Duplex 25G Ethernet Networks

This emerging application utilizes 8-fiber MPO connectors and cables for BASE-8 configurations. While currently in early adoption phase, this application is projected for rapid growth as 25G data rate equipment becomes more prevalent.

40G and 100G SR4 or PSM4 Ethernet Parallel Transmission Networks

These applications typically use MPO 12-fiber connectors and cables, though only 8 fibers are utilized for SR4 40G or 100G Ethernet transmission. The advantage of 12-fiber cables lies in their compatibility with duplex 10G networking, offering greater flexibility and multiple purposes with minimal cost difference.

The three polarity methods Type A, Type B and Type C are used to guarantee proper bi-directional allocation.

Packaging

Products are packaged in OPP bags within carton boxes to ensure protection against damage during delivery.

Contact: WHATSAPP +8613534063703

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer located in Shenzhen, China.

What's your MOQ?

MOQ can be 1 piece, but we don't recommend ordering single units as costs and prices will be higher. Larger quantities receive more competitive pricing.

What's the price?

Pricing depends on quantity. We provide our best pricing based on your specific quantity requirements.

Can you quote FOB price?

Yes, but due to typically small size and weight, most shipments are via air couriers (DHL, TNT, UPS, FEDEX). EXW or CFR pricing is often more practical. We provide competitive logistics solutions for all shipment sizes.

How is your quality?

Our production follows IEC and European standards in near dust-free workshops using imported production and quality control equipment. All products undergo 100% testing before delivery.

What's your lead time?

We operate three factories in China. For fiber optic patch cords, lead time is 2-3 working days for 5,000 pieces. Regular products are typically in stock, and we accommodate urgent orders.

What's your warranty?

Patch cords carry a 2-year warranty against non-artificial damage from delivery date. For artificial damage, we provide free repairs with customer covering freight costs.

What's your packing?

We use international export packaging and can print customer logos upon request.

Can you do OEM/ODM?

Yes, we support OEM/ODM and can sign confidentiality agreements.

Can I have a sample?

Free samples available for adaptors, attenuators, patch cords, and pigtails with customer covering freight. Higher-value products require sample charges refundable upon order placement.

How can I order?

1. Send inquiry with product specifications and quantity
2. We provide pricing and lead time
3. Upon acceptance, we issue Proforma Invoice
4. Production begins after payment receipt
5. We confirm shipping details and provide tracking
6. We prioritize long-term partnership requirements

What are your payment terms?

T/T, Western Union, PayPal, MoneyGram. For large amounts: 50% deposit, 50% balance before delivery.
