MTP Breakout Harness Cable with 0.35dB Elite Low Loss Connector for Easy Migration from 10GbE to 40GbE or 100GbE and 500 pcs/day Production

Brand Name:	New Light
Model Number:	MPO / MTP - MPO / MTP
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Connector Type:

MPO / MTP TO MPO / MTP

Mode Type:

Core Type:

12 Core

Certificate:

CE , ISO , RoHS

Delivery Time:

2-7 Working Days After Received Deposit

Production Ability:

500 Pcs / Day

Payment Term:

T/T , 30% Deposit In Advance

Connector:

MPO,MTP

Color:

Aqua,orange,yellow,Yellow/ Red/ Aqua

Supply Ability:

500 pcs per day

Highlight:

mpo fiber cable

mpo to mpo cable

Product Description

MTP – LC/UPC Duplex 12 Fibre OM3 Breakout Harness Cable With Low Loss Connector

Product Description

MTP - LC/UPC duplex 12 Fibre OM3 Breakout Harness Cable with low loss connector

MPO MTP Cable Overview

New Light Complete Connect MTP - LC Fan-out harness cables are easily installed. The MTP connector simply clicks into place and ensures the polarity across your Fibre Channel is maintained. The cables are fully compatible with other MTP based fibre systems. No specialist tools or equipment are required.

Our range of 3mm 12 fibre cables and 3.8mm 24 fibre cables ensures that a small bend radius is achievable, the cable weight is reduced by 65% and the space in cable trays is reduced by 60% compared to traditional tight buffered or loose tube fibre.

MPO MTP Cable Features

US Conec MTP connector, Senko MPO Plus premium connector
OS2, OM3, OM4 fiber grades (OM1 and OM2 available)
0.35dB Elite low loss MTP/MPO connector as well standard versions of 0.6/0.75dB
Factory terminated and tested
Allow easy migration from 10GbE to 40GbE or 100GbE
Pulling eyes are provided as an option to protect the fiber ends during installation

MPO MTP Cable Technical Parameter

Item	Technical Parameters
Connector	MPO/MTP(F or M) \| MPO/MTP (F or M)
Operation Temperature	-40°C ~ +80°C
Storage Temperature	-40°C ~ +85°C
Insertion Loss	SM: ≤ 0.75dB (standard value), ≤0.35dB (typical value); MM:≤ 0.50dB (standard value), ≤0.35dB (typical value);
Return Loss	SM:≥60dB; MM:≥35dB
The MPO end type	Male: with guide pin; Female: without guide pin
Fiber count	8,12&24 fiber
Connector type of the other end	MPO-female , MPO-male , FC , SC , ST , MU , LC , E2000
Fiber mode	Single-mode (G652,G655,G657), multi-mode (50, 62.5, OM2, OM3, OM4)
Fiber cable type	250um ribbon fiber,ribbon cable,Bundle fiber optic cable

Application

Application within duplex 1G to 10G Ethernet networks
For these applications, MPO patch cables with 12 fibre connectors and 12 fibre cables are predominantly used. They are mainly located in distribution areas where high density patching fields are required. Using MPO patch cables as opposed to standard duplex LC - LC patch cables increases the patching density by a factor of six. Typically, these MPO patch cables will be polarity C and will have male MPO connectors and will connect to polarity C trunk/backbone MPO cables. The trunk cables will have MPO female connectors.

Application within duplex 25G Ethernet networks
This is the newest application for MPO patch cables. These cables use 8 fibre MPO connectors and 8 fibre cable and are used for BASE-8. although at the time of writing this application is in the early adoption phase it is projected to grow rapidly as more equipment is produced at 25G data rates.

Application within 40G and 100G SR4 or PSM4 Ethernet parallel transmission networks
Typically, these cables will use an MPO 12 fibre connector and 12 fibre cable. However, in the transmission of SR4 40G or 100G Ethernet only 8 fibres within these cables are used. The advantage of using 12 fibre cables (as opposed to 8 fibre) is that the cabling is often used alongside duplex 10G networking and so these cables can have multiple purposes and offer greater flexibility with negligible cost difference.

The three polarity methods Type A, Type B and Type C are used to guarantee the right bi-directional allocation.

Packaging

We will pack it by OPP bag and carton box outside to protect the goods from damage during delivery.

Frequently Asked Questions

1. Are you manufacturer?

Yes, we are manufacturer in Shenzhen, China.

2. What's your MOQ?

MOQ can be 1 pcs, but we are not suggest to order 1 pcs, because the cost will be higher, so that the price will be higher than your budget.

3. What's the price?

The price is according to your quantity. After you let us know your quantity, we will offer our best price for you. Big Quantity will get very competitive price.

4. Can you quote FOB price?

Yes we can, But due to the size and weight is not big, most are delivery by air, DHL, TNT, UPC, FEDEX, etc. So it it difficult to do FOB price. The best way is let us know your detailed specifications and quantity, we will offer the freight with products price for your reference.

We have very competitive price logist. If your quantity is big and there are dozens of carton boxes, we can figure out freight by sea for your reference.

EXW price or CFR price will be better. You can contact us for more solution if you need.

5. How is your quality?

Our production is according to IEC, Europe standard production, almost closed to dust-free workshop. Imported production equipment and quality control equipment. Especially MTP Daisi equipments.

All the products are 100% test before delivery.

6. Whats your lead time?

We have three factories in China. One factory for fiber optic cable production, two factories for patch cord, PLC, ODF, adaptor, attenuators, etc.

For fiber optic patch cord, the lead time can be 2-3 working days for 5000 pcs. regular products we are have it in stock. We can deal with urgent order for you. More informations, you can feel free to contact us.

7. Whats your warranty?

For patch cord, we have 2 years warranty since delivery, but only responsible for non-artificial damage. For artificial damage, we can repare it for you for free, but freight will be paid by your side.

8. Whats your packing?

We are using international export package. attached some packing of different products for your reference. We also can print your logo on the packing.

9. Can you do OEM/ODM?

Yes, we can. We are manufacturer, all products accept OEM/ODM. we can sign the Confidentiality agreement.

10. Can I have a sample?

It depends on which products, for adaptor, attenuator, patch cord, pigtail, we can provide the sample for free. But freight repaid by your side.

For big value products, we can't offer it for free, sample charge and freight repaid first, after you placed order, the sample charge will be returned.

11. How can I order?

1. send mail to us or send inquiry. let us know the products name, detailed specifications, quantity. Provide your receive address if you need us to figure out freight for you.

2. After we know your requirements, will offer our best price for you, with lead time. The price is according to your quantity.

3. When you accept the quotation, we will make Profoma Invoice with our bank account.

4. We will arrange the production for you after we received payment.

5. Before we delivery will confirm the receive information with you again. and will send the tracking number to you after delivery.

6. We will try our best to meet your requirements for long-term cooperation.

12. What your payment term?

T/T, Western Union, Paypal, MoneyGram at once. For big amount, can 50% deposit in advance, 50% balance paid before delivery.
