Custom Made Fiber Optic Patch Panel 3 LGX Adapter Plates For Rack Mount Patch Panel

Brand Name:	New light
Model Number:	6/24 /48 core ptach panel
MOQ:	1~10000
Price:	10~100
Packaging Details:	opp bag+Carton box
Payment Terms:	T/T, Western Union, MoneyGram ,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ROHS ;ISO9001

Front Panel:

LC , SC , ST , FC , E2000

Size:

19 Inch

Interface:

Powder Coated

Product Name:

Custom Made Fiber Optic Patch Panel 3 LGX Adapter Plates For Rack Mount Patch Panel

Weight:

Material:

Phosphor Bronze

Storage Temperature:

-45°C~+60°C

Product Type:

Slide-out Drawer Enclosure With Splice Trays

Dimensions:

1.75"H X 17.0"W X 14.0"D,485mmx294mmx44mm

Type:

2U,draw Type Fiber Optic Path Panel,1U,Singlemode Or Mutil Mode

Supply Ability:

10000 per day

Highlight:

fiber optic accessories

fiber optic termination panel

Product Description

1U 19" Patch Panel for 3 LGX Adapter Plates for rack mount patch panel

Features:

LC (SFF data center standard), SC discrete interface
OS1/2, OM3, OM4 fibre grades (OM1 and OM2 available)
12 and 24 fibre versions - 12 LC (Duplex) / SC (Simplex) optical parts
Polarity A (standard), B or C
Factory terminated and tested
High performance zirconia sleeve adaptors

Product description:

Our 1RU Patch Panel provides many flexible fiber patching configurations in a 1RU form factor. It accommodates (3) LGX adapter plates, MPO break modules or splitter cassettes. Slide out trays and removable front and back doors allow easy access to the patch bay. Multiple cable retention brackets and tie down spots allow for convenient cable management. Spring-loaded stop latches keep the tray securely in place when retracted. Rackmount installs into a standard 19-inch rack. Includes non-flush brackets for 19-inch racks. Adapter plates, 23-inch mounting brackets, and 19-inch flush mount brackets are sold separately.

Slide-Out Patch Panel Enclosures are designed for both high and low-density patching and splicing applications. Constructed from durable 14 gauge aluminum, these enclosures are lightweight and rugged. Cable organization features include may slack management spools, cable routing rings and tie down bridge stances. All our rack mount enclosures fit standard 19-inch racks and cabinets.

12 fiber 24 core, 48, 72 and 144 fiber configurations. Standard 1U, 2U, 3U and 4U (LIU) Fiber Optic Patch Panels and Optical Distribution Frames (ODF). Take a look at our rack mount patch panel .

The spice tray inside the box is made of ABS material which available for 0.9mm, 2.0mm &3.0mm Fiber Cable.

Each Patch Panel is fully loaded with panels, adaptors, splices trays and accessories and is ready for installation.

Custom Made Fiber Optic Patch Panel 3 LGX Adapter Plates For Rack Mount Patch Panel 0

Parameter		Unit	FDF-1U	FDF-2U	FDF-3U
Fiber Capacity		Core	≤24	≤48	≤72
Number of Tray		PCS	1	2	4
	Height		1U	2U	3U
Dimension	Width	mm	482	482	482
	Depth	mm	305	305	305
Remark			Rack Mount	Rack Mount	Rack Mount

Applications:

· Telecommunication networks

· Local Area Networks

· FTTH

· CATV networks

· Active device termination

Features & Benefits:

· Low excess loss & high performance

· Retractable splicing tray

· Convenience and ease of handling

· Indoor use, outdoor use customizable

Projects	Parameter
Operating temperature	-25℃~+40℃
Storage temperature	-25℃~+55℃
Relative humidity	≤85％(+30℃)
Air pressure	70Kpa~106Kpa
Color	Black

Custom Made Fiber Optic Patch Panel 3 LGX Adapter Plates For Rack Mount Patch Panel 1

Dimension:

Model	fiber quantity	Height	Dimension(LxWxH)
rack mount	12 /24 /48 /96 core	1U	430354.144mm

Custom Made Fiber Optic Patch Panel 3 LGX Adapter Plates For Rack Mount Patch Panel 2
