1U 19" Optical Distribution Frame For LGX Adapter Plates For Rack Mount Patch Panel

1U 19" Optical Distribution Frame For LGX Adapter Plates For Rack Mount Patch Panel
1U 19" Optical Distribution Frame For LGX Adapter Plates For Rack Mount Patch Panel 1U 19" Optical Distribution Frame For LGX Adapter Plates For Rack Mount Patch Panel 1U 19" Optical Distribution Frame For LGX Adapter Plates For Rack Mount Patch Panel

Large Image :  1U 19" Optical Distribution Frame For LGX Adapter Plates For Rack Mount Patch Panel

Product Details:
Place of Origin: China
Brand Name: New light
Certification: ROHS ;ISO9001
Model Number: 6/24 /48 core ptach panel
Payment & Shipping Terms:
Minimum Order Quantity: 10 pcs
Price: USD 68-120 set
Packaging Details: opp bag+Carton box
Delivery Time: 2-15 working days
Payment Terms: T/T, Western Union, MoneyGram ,Paypal
Supply Ability: 10000 per day

1U 19" Optical Distribution Frame For LGX Adapter Plates For Rack Mount Patch Panel

Description
Aplication: Data Centers,pre-terminated Installations Front Panel: LC , SC , ST , FC , E2000
Size: 19 Inch Interface: Powder Coated
Product Name: 24 Fiber Rack Mounted MPO/MTP Fiber Optic Patch Panel Tray: 12/24/48/72/96 Fiber
Weight: 6kg Material: Phosphor Bronze
Storage Temperature: -45°C~+60°C Product Type: Slide-out Drawer Enclosure With Splice Trays
Dimensions: 1.75"H X 17.0"W X 14.0"D,485mmx294mmx44mm Type: 2U,draw Type Fiber Optic Path Panel,1U,Singlemode Or Mutil Mode
High Light:

fiber optic accessories

,

fiber optic termination panel

1U 19" Patch Panel for LGX Adapter Plates for rack mount patch panel



Product description:



Rack Mount Adapter Plate Holders offer a compact, cost effective way to breakout fiber in a rack mount environment where splicing is not necessary. Durable, powder coated, steel construction (standard color black).



12 fiber 24 core, 48, 72 and 144 fiber configurations. Standard 1U, 2U, 3U and 4U (LIU) Fiber Optic Patch Panels and Optical Distribution Frames (ODF). Take a look at our rack mount patch panel .

The spice tray inside the box is made of ABS material which available for 0.9mm, 2.0mm &3.0mm Fiber Cable.

Each Patch Panel is fully loaded with panels, adaptors, splices trays and accessories and is ready for installation.



The 1RU and 3RU rack mount models hold standard RLH Fiber Adapter Plates (black) available separately. The Adapter plate holders are also compatible with any LGX foot print adapter plates.

Slide-Out Patch Panel Enclosures are designed for both high and low-density patching and splicing applications. Constructed from durable 14 gauge aluminum, these enclosures are lightweight and rugged. Cable organization features include may slack management spools, cable routing rings and tie down bridge stances. All our rack mount enclosures fit standard 19-inch racks and cabinets.





1U 19" Optical Distribution Frame For LGX Adapter Plates For Rack Mount Patch Panel 0



Features:


MTP/MPO standard compliant multifibre connector
LC (SFF data center standard), SC discrete interface
OS1/2, OM3, OM4 fibre grades (OM1 and OM2 available)
12 and 24 fibre versions - 12 LC (Duplex) / SC (Simplex) optical parts
Polarity A (standard), B or C
Factory terminated and tested
High performance zirconia sleeve adaptors





Parameter Unit FDF-1U FDF-2U FDF-3U
Fiber Capacity Core ≤24 ≤48 ≤72
Number of Tray PCS 1 2 4
  Height   1U 2U 3U
Dimension Width mm 482 482 482
  Depth mm 305 305 305
Remark   Rack Mount Rack Mount Rack Mount





Applications:



· Telecommunication networks

· Local Area Networks

· FTTH

· CATV networks

· Active device termination



Features & Benefits:



· Low excess loss & high performance

· Retractable splicing tray

· Convenience and ease of handling

· Indoor use, outdoor use customizable



Projects Parameter
Operating temperature -25℃~+40℃
Storage temperature -25℃~+55℃
Relative humidity ≤85%(+30℃)
Air pressure 70Kpa~106Kpa
Color Black



1U 19" Optical Distribution Frame For LGX Adapter Plates For Rack Mount Patch Panel 1

Dimension:



Model fiber quantity Height Dimension(LxWxH)
rack mount 12 /24 /48 /96 core 1U 430*354.1*44mm





1U 19" Optical Distribution Frame For LGX Adapter Plates For Rack Mount Patch Panel 2
