Mini Outdoor Optical Fiber Patch Cord With SC / APC Connector Huawei Model

Mini Outdoor Optical Fiber Patch Cord With SC / APC Connector Huawei Model
Mini Outdoor Optical Fiber Patch Cord With SC / APC Connector Huawei Model
Mini Outdoor Optical Fiber Patch Cord With SC / APC Connector Huawei Model Mini Outdoor Optical Fiber Patch Cord With SC / APC Connector Huawei Model Mini Outdoor Optical Fiber Patch Cord With SC / APC Connector Huawei Model

Large Image :  Mini Outdoor Optical Fiber Patch Cord With SC / APC Connector Huawei Model

Product Details:
Place of Origin: China
Brand Name: NewLight
Certification: IS09001-2008.ROHS
Model Number: NL001
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negoatiate
Packaging Details: 1 pcs per pack
Delivery Time: 3 to 5 working day
Payment Terms: T/T, Western Union, MoneyGram,Paypal
Supply Ability: 10000pcs/month

Mini Outdoor Optical Fiber Patch Cord With SC / APC Connector Huawei Model

Description
Connector: LC-LC Application: FTTA FTTH BBU RRU RRH LTE & Base Station,For ODF Internal Link,For Room Equipment Internal Link,FTTH/Test Equipments/TV/LAN/Telecommunication Equipments
Length: Any Length Is Customizable Connector Type: SC/FC/LC/ST/MU/DIN/D4/MTRJ/MPO
Type: Single Mode/Multi-mode Material: PVC/LSZH
Color: Yellow,Orange Or Others,aqua Or Cusomized Wavelength: 850 Nm,1310nm,1310nm Or 1550nm
Fiber Type: G652D,G655,anything,SM Or MM
High Light:

sc sc fiber patch cord

,

single mode fiber optic cable

Mini Outdoor Patch Cord with SC / APC Connector Huawei Model


Description:


New design Toptap SC FTTA outdoor patch cord assemblies provide an cost effective, easy, environmental seal and mechanical protection for 1 fibers simplex SC style connections. Inside cover can protect ferrule end face far away scratch when mating with receptacle; Special fool-proofing design equal to HUAWEI Mini SC connector has blind-mating function; One hand Bayonet-style mechanical latch. The assemblies guarantee an easy, one-step connection system with the combined push-pull insertion and bayonet-style mechanical latch. It provides quick installation solutions and has good performance on mating receptacle / Adapter. Cable can be armoured or non-amoured. The industrial panel-mount, plastic adapters serve as a sealed feed-through for the fiber connection. The new industrial integrated flange-mount adapters are designed for tight, side-by-side applications.

Features :

1. Cost effective solution for in house termination
2. IP67 Water immersion and Dust protection for hash environment ·
3. Chemical Resistance ·
4. Simple assembly requiring no special tools ·
5. Push-pull insertion with bayonet-style mechanical latch provides easy installation and removal
6. Durable mechanical mating, minimum of 500 matings
7. Wide range of operational temperature for outside plant -40 to+85°C
8. SC/APC IL<0.3 typically.
9.100% optically tested to ensure quality performance assemblies.

Application:
-FTTA FTTH FTTX
-Local Area Network (LAN)
-Data communication network
-Telecommunication optical transmission network
-Optical access network(OAN)
-Active device termination
-Fiber optics data transmission(FODT)
-Test Equipment
-CATV

Specification:

Model NumberIP67 field fast assembly mini SC/APC H connector
ApplicationFTTH BBU RRU FTTX Network
Waterproof LevelIP67
MaterialFlame-Retardant
Connector TypeUPC/APC

Mini Outdoor Optical Fiber Patch Cord With SC / APC Connector Huawei Model 0
Mini Outdoor Optical Fiber Patch Cord With SC / APC Connector Huawei Model 1


Ordering Options:

Both singlemode and multimode versions fiber optic patch cord come with a zirconia ceramic ferrule with pre-polished PC,UPC,APC profile and convex spherical end.
These end face types allow for faster polishing, and low back reflection and optical loss, while ensuring maximum repeatability

Mini Outdoor Optical Fiber Patch Cord With SC / APC Connector Huawei Model 2



Connector typeSC,FC,ST,LC,E2000,DIN,MU,MTRJ,etc
PolishUPC,APC,PC
Cable typeSimplex,Duplex straight,Duplex Reverse
FiberSM(G652),62.5/125um,50/125um,OM2,OM3,SM(G655)
Cable JacketRiser,Plenum,LSZH
Cable Diameter3.0mm,2.0mm,0.9mm,etc
Cable LengthLength in meter


Type:

* Connector type: FC,SC,ST,LC,MT-RJ,MU,etc.
* Ferrule endface: PC,UPC,APC,etc.
* Fiber type: single mode,polarization-maintaining optical fiber,multimode 50/125,mutimode 62.5/125,etc.
* Cable diameter: 0.9mm,2.0mm,3.0mm,etc.
* Number of fiber connected: single-core connector,dual-core connector and multi-core connector.




Features

* Good durability
* Good exchangeability
* High temperature stability
* Low insertion loss and back reflection loss
* Superior quality standard PC/UPC/APC Polishing
* Standard: Telcordia GR-326-CORE,TIA/EIA and IEC

Mini Outdoor Optical Fiber Patch Cord With SC / APC Connector Huawei Model 3

Mini Outdoor Optical Fiber Patch Cord With SC / APC Connector Huawei Model 4
