Mini Outdoor Optical Fiber Patch Cord with SC/APC Connector IP67 Waterproof for FTTA Applications

Brand Name:	NewLight
Model Number:	NL001
MOQ:	1~100000
Price:	0.1~100
Packaging Details:	1 pcs per pack
Payment Terms:	T/T,Western Union,MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Connector:

LC-LC

Application:

FTTA FTTH BBU RRU RRH LTE & Base Station,For ODF Internal Link,For Room Equipment Internal Link,FTTH/Test Equipments/TV/LAN/Telecommunication Equipments

Length:

Any Length Is Customizable

Connector Type:

SC/FC/LC/ST/MU/DIN/D4/MTRJ/MPO

Type:

Single Mode/Multi-mode

Material:

PVC/LSZH

Color:

Yellow,Orange Or Others,aqua Or Cusomized

Wavelength:

850 Nm,1310nm,1310nm Or 1550nm

Fiber Type:

G652D,G655,anything,SM Or MM

Connector:

LC-LC

Application:

FTTA FTTH BBU RRU RRH LTE & Base Station,For ODF Internal Link,For Room Equipment Internal Link,FTTH/Test Equipments/TV/LAN/Telecommunication Equipments

Length:

Any Length Is Customizable

Connector Type:

SC/FC/LC/ST/MU/DIN/D4/MTRJ/MPO

Type:

Single Mode/Multi-mode

Material:

PVC/LSZH

Color:

Yellow,Orange Or Others,aqua Or Cusomized

Wavelength:

850 Nm,1310nm,1310nm Or 1550nm

Fiber Type:

G652D,G655,anything,SM Or MM

Supply Ability:

1000000

Highlight:

sc sc fiber patch cord

single mode fiber optic cable

Product Description

Mini Outdoor Optical Fiber Patch Cord With SC/APC Connector Huawei Model

The Toptap SC FTTA outdoor patch cord assemblies provide a cost-effective, environmentally sealed solution with mechanical protection for 1-fiber simplex SC style connections. Featuring a protective inside cover to prevent ferrule end face scratches during mating, special fool-proofing design equivalent to HUAWEI Mini SC connector with blind-mating function, and one-hand bayonet-style mechanical latch for easy installation.

Key Features

Cost-effective solution for in-house termination
IP67 Water immersion and Dust protection for harsh environments
Chemical Resistance
Simple assembly requiring no special tools
Push-pull insertion with bayonet-style mechanical latch for easy installation and removal
Durable mechanical mating, minimum of 500 matings
Wide operational temperature range for outside plant: -40°C to +85°C
SC/APC IL <0.3 typically
100% optically tested to ensure quality performance

Applications

FTTA FTTH FTTX
Local Area Network (LAN)
Data communication network
Telecommunication optical transmission network
Optical access network (OAN)
Active device termination
Fiber optics data transmission (FODT)
Test Equipment
CATV

Specifications

Model Number	IP67 field fast assembly mini SC/APC H connector
Application	FTTH BBU RRU FTTX Network
Waterproof Level	IP67
Material	Flame-Retardant
Connector Type	UPC/APC

Ordering Options

Both singlemode and multimode versions of fiber optic patch cords come with zirconia ceramic ferrules with pre-polished PC, UPC, APC profiles and convex spherical ends. These end face types allow for faster polishing, low back reflection and optical loss, while ensuring maximum repeatability.

Connector type	SC, FC, ST, LC, E2000, DIN, MU, MTRJ, etc
Polish	UPC, APC, PC
Cable type	Simplex, Duplex straight, Duplex Reverse
Fiber	SM(G652), 62.5/125um, 50/125um, OM2, OM3, SM(G655)
Cable Jacket	Riser, Plenum, LSZH
Cable Diameter	3.0mm, 2.0mm, 0.9mm, etc
Cable Length	Length in meter

Product Types

Connector type: FC, SC, ST, LC, MT-RJ, MU, etc.
Ferrule endface: PC, UPC, APC, etc.
Fiber type: single mode, polarization-maintaining optical fiber, multimode 50/125, multimode 62.5/125, etc.
Cable diameter: 0.9mm, 2.0mm, 3.0mm, etc.
Number of fiber connected: single-core connector, dual-core connector and multi-core connector.

Quality Features

Good durability
Good exchangeability
High temperature stability
Low insertion loss and back reflection loss
Superior quality standard PC/UPC/APC Polishing
Standard: Telcordia GR-326-CORE, TIA/EIA and IEC

Frequently Asked Questions

Q: Are you a trading company or manufacturer?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 7-15 days if the goods are in stock. Or it is 15-30 days if the goods are not in stock, depending on quantity.

Q: Do you provide samples? Is it free or extra?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: How about your after-sales service?

A: We offer you 24 hours service phone, 9 hours with mail.

Q: What is your terms of payment?

A: Payment <= 10000USD, 100% in advance. Payment >= 10000USD, 30% T/T in advance, balance before shipment.
