Product Details:
|
| Certification: | ISO9001,ROHS,CE,CE And ROHS,ISO9001/CE/ROHS | Fiber Type: | Singlemode G652D ,G657A |
|---|---|---|---|
| Outer Jacket Material: | LSZH | Strength Member Material: | KFRP / FRP / Steel Wire |
| Packaging: | Wooden Wheel | Test Repor: | Out Package Of The Cable |
| Fiber Struction: | Figure8 | Usage: | Aerial |
| Type: | Single-Mode Or Multi-Mode | Jacket Material: | LSZH,PVC,PE,TPU,PVC/LSZH |
| High Light: | duplex fiber optic patch cable,fiber optic drop cable |
||
waterproof fiber optic cable GYTS GYTA GYFTY armoured fiber optic cable
Description
Fiber optic cable GYTS, 2~144 fibers, central strength member (steel), jelly filled and fiber contained central loose tube, PP filler (if necessary) standed, water blocking jelly, aliminium polyethylene laminate, PE outer sheath, G652D SM fiber
1.Product name: 2-288cores GYTS/GYTA G652D Fiber Optic Cable
2.Color:Black or gray
3.Jacket:PE/PVC/LSZH
4.Application:Indoor or outdoor telecommunication,Network
5.Core:2 to 288 cores
6.Length:0.5m/1m/3m/5m,2KM/roll,custom
7.Working Temperature:-40~+60℃
8.Fiber:G652D, G655, G657, A1a(50/125),A1b(62.5/125),OM3
9.Package:2km/roll
10.OEM and ODM are welcome over 10 years.
11.Certification: CE,Rohs,UL,ISO9001
Features and Applications
• Small cable diameter, high tensile strength
• Good mechanical and temperature performance
• Robust 900μm tight buffered fibers for ease of termination
• Outer jacket has good anti-ultraviolet, water blocking performance
• Glass yarn strength members and steel tape armor for rodent resistance
• Short run interconnect links
• Under floor or ceiling spaces
• Installation in trunking, LAN backbones
• Duct/conduit, aerial, direct burial application
• Fiber backbones in riser and horizontal configurations
Standards
GYTS cable complies with Standard YD/T 901-2001as well as IEC 60794-1.
| G.652 | G.655 | 50/125μm | 62.5/125μm | ||
| Attenuation | @850nm | ≤3.0 dB/km | ≤3.0 dB/km | ||
| (+20℃) | @1300nm | ≤1.0 dB/km | ≤1.0 dB/km | ||
| @1310nm | ≤0.36 dB/km | ≤0.40 dB/km | |||
| @1550nm | ≤0.22 dB/km | ≤0.23dB/km | |||
| Bandwidth (Class A) | @850nm | ≥500 MHz·km | ≥200 MHz·km | ||
| @1300nm | ≥1000 MHz·km | ≥600 MHz·km | |||
| Numerical Aperture | 0.200±0.015NA | 0.275±0.015NA | |||
| Cable Cut-off Wavelength λcc | ≤1260nm | ≤1480nm | |||
Packing
| Item | Index |
| Length and packaging | 2000m/3000 plywood reel |
| Packaging details | wooden wheel |
Application
Ideal Solution for Tight-Buffered Distribution Waterproof Indoor/Outdoor Cable
Distribution waterproof indoor/outdoor cable is easy to install and handle. With high mechanical strength, rodent and waterproof protection, the ideal application of the cable is for LAN backbones, direct burial, ducts, trunking, and under floor or ceiling spaces.
Packaging & Shipping
NEW LIGHT offers standardized packaging of cable, and we can ship it as soon as possible for adequate inventory. We pack the cable with roll, then put it into carton. The package provide good protection for cable. Usually we only attach test report on the out package of the cable, but we could also mark as your requirements.
FAQ
Q:Are you trading company or manufacturer ?
A:We are factory.
Q:How long is your delivery time?
A:Generally it is 7-15 days if the goods are in stock . Or it is 15-30 days if the goods are not in stock, it is according to quantity.
Q:Do you provide samples ? Is it free or extra ?
A:Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q:How about your after-sales service?
A:We offer you 24 hours service phone, 9 hours with mail.
Q:What is your terms of payment ?
A:Payment<=10000USD, 100% in advance . Payment>=10000USD, 30% T/T in advance , balance before shippment.
