50/125um 10Gb OM3 Lc Singlemode Fiber Pigtail Fusion Splicing

50/125um 10Gb OM3 Lc Singlemode Fiber Pigtail Fusion Splicing
50/125um 10Gb OM3 Lc Singlemode Fiber Pigtail Fusion Splicing
50/125um 10Gb OM3 Lc Singlemode Fiber Pigtail Fusion Splicing 50/125um 10Gb OM3 Lc Singlemode Fiber Pigtail Fusion Splicing 50/125um 10Gb OM3 Lc Singlemode Fiber Pigtail Fusion Splicing 50/125um 10Gb OM3 Lc Singlemode Fiber Pigtail Fusion Splicing

Large Image :  50/125um 10Gb OM3 Lc Singlemode Fiber Pigtail Fusion Splicing

Product Details:
Place of Origin: ShenZhen , China
Brand Name: New Light
Certification: CE , ISO , RoHS
Model Number: LC/ UPC
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: can be negotiated
Packaging Details: OPP bag + carton box
Delivery Time: 2-7 working days after receive payment
Payment Terms: L/C, T/T, Western Union, MoneyGram , paypal
Supply Ability: 12000 pcs / day

50/125um 10Gb OM3 Lc Singlemode Fiber Pigtail Fusion Splicing

Description
Products Name: Lc Fiber Pigtail Connector Type: LC( Can Be ST , FC , SC , MPO , MTRJ , MU )
Mode Type: SM Cable Color: Yellow
Cable Diameter: 0.9mm Cable Length: 1 M (can Be Customized )
Insertion Loss: ≤ 0.2 DB Return Loss: ≥ 40dB
Delivery Time: 2-7 Working Days Payment Term: 30% Deposit In Advance , 70% Balance Paid Before Delivery
High Light:

OM3 Lc Singlemode Fiber Pigtail

,

125um Singlemode Fiber Pigtail

,

10Gb Fusion Splicing Pigtail

fusion splicing simpex singlemode 50/125um 10Gb OM3 lc fiber pigtail



Premium Plus lc fiber pigtails and Patchcords are ideal for fusion splicing the required fiber connectivity for structured cabling systems including Data Centers, Broadband CATV, Passive Optical Network PON, WDM or DWDM multiplexing, FTTh and voice services in ATM and SONET metropolitan and access networks. Quick turn service is available with orders of up to 100 Pigtails or 20 Pigtail Kits, and ships within three business days. Contact customer service for details.





Features of  lc fiber pigtail



Available LC, LC/APC, SC, SC/APC, ST, FC and FC/APC connector options
Pigtails kits of 6, 8, 12 or 16 following TIA color sequence
TIA color-coded LC and SC connectors with white 900-micron boots
Fiber options: OS2, OM1, OM3, and OM4
100% tested for insertion loss and single mode return loss
Premium Plus Series cords include a Limited Lifetime Warranty when used with other Leviton cabling and installed by a Leviton certified contractor
Quick-turn service for fast delivery



Applications of  lc fiber pigtail


1) CATV, metro test equipment;
2) Telecommunication networks;
3) Local area networks (LAN);
4) Wide area networks (WAN);
5) Premise installations;

6) Data processing networks;





Specification S.M M.M
PC UPC APC
Insertion Loss(dB) <=0.30dB <=0.20dB <=0.20dB <=0.30dB
Return Loss(dB) >=50dB >=55dB >=60dB -
Durability(1000 matings) <=0.20dB
Operating Temperature -40~+85℃
Storage Temperature -40~+85℃
Cable Diameter(mm) 0.9/2.0/3.0
Cable Length(m) 1M, 2M, 3M, 5M, Customized
Specification S.M M.M
PC UPC APC
Insertion Loss(dB) <=0.30dB <=0.20dB <=0.20dB <=0.30dB
Return Loss(dB) >=50dB >=55dB >=60dB -
Durability(1000 matings) <=0.20dB
Operating Temperature -40~+85℃
Storage Temperature -40~+85℃
Cable Diameter(mm) 0.9/2.0/3.0
Cable Length(m) 1M, 2M, 3M, 5M, Customized

Pigtails are used for splice applications when terminating outside plant cable. It’s consists of a connector and a special length



Fiber optic connectors of lc fiber pigtail are designed and polished to different shapes to minimize back reflection, which is particularly important in single mode applications. According to this connector polish types, there are PC, UPC, and APC fiber patch cords. This post PC vs UPC vs APC Connector: Selecting the Right Fiber Connector Type presents the difference of PC, UPC, and APC. Nowadays PC polish type has been replaced by UPC type. Whether you choose UPC or APC depends on your actual application. Since APC provides less insertion loss than UPC, the APC fiber patch cables are more applicable for high bandwidth applications and long-distance links, such as FTTx, passive optical network (PON) and wavelength division multiplex (WDM). Whereas UPC fiber patch cords apply to optical systems that are less sensitive to insertion loss such as digital TV and telephony.

50/125um 10Gb OM3 Lc Singlemode Fiber Pigtail Fusion Splicing 0









1.Are you the real manufacturer?
Us. We are the real manufacturer with 15 year’s history.


2.What’s the MOQ?
Us. The MOQ of Fiber Optic cable is 1km

.
3.What’s delivery time?
Us. The general delivery time is 5-7 days after order confirmed. It depends on the order quantity.


4.How to Store the Optical Fiber Cable Properly?
Us. Store the drum indoor before using, the drum should place sideways not on the end.


5. Can you supply customized products and logo?
Yes. We supply OEM service. You can send us your drawing.


6.What’s your payment terms?
Us. We accept T/T,L/C,Western Union,D/P etc. 30% in advance and 70% before shipment.





Payment term and delivery



1. Payment : T/T , L/C , Paypal , Westen Union , Moneygram

2. 30% deposit in advance , 70% balance paid before delivery .

3. Package : internatinal standard package ( OPP bag + Carton Box )

4. Delivery time : 2-7 working days ( according to your quantity )after received payment .

5. Warranty : 3 year (after delivery ) .

6. Shipping method : BY air ( DHL , TNT , UPS ,Fedex ) , By sea (according to your requirements ).
