15dB APC Polish Single Mode Fixed Fiber Optic Attenuator for LC SC Connectors

Brand Name:	New Light
Model Number:	LC002
MOQ:	10
Price:	1~30
Packaging Details:	10pcs per pack
Payment Terms:	T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Color:

Green / Red

Connector:

SC LC

Polish:

UPC / APC

Mode:

Single Mode

Attenuator:

Material:

Plastic

Supply Ability:

10000/month

Highlight:

LC SC Fixed Fiber Attenuator

APC 15dB Fixed Fiber Attenuator

250mW Fiber Optical Attenuator

Product Description

Plastic 15dB LC SC APC Fixed Fiber Attenuator Male To Female

This plastic 15dB LC SC APC Fixed Fiber Attenuator is a precision optical passive device designed for professional fiber optic applications. It features a male to female connector configuration for seamless integration into existing fiber optic systems.

WHATSAPP: 008613534063703

Product Overview

As an optical passive device, fiber attenuators are primarily used for debugging optical power performance, calibrating optical instruments, and attenuating fiber signals to maintain optical power at stable, desired levels in transmission links without altering the original transmission wave.

Main Features

Low insertion loss and back reflection loss
High precision of mechanical dimensions
Compliant with Telcordia GR-326-Core, IEC, TIA standards
RoHS compliant

Technical Specifications

Standard Attenuation Values

Type	Attenuation Range
PC	0dB to 20dB (1dB step)
APC	25dB
Custom	Step to be specified

Performance Parameters

Parameter	Specification
Operating Wavelength	1260nm~1620nm
Return Loss	SPC≥40dB, UPC≥50dB, APC≥60dB
Attenuation Tolerance	Standard: 0dB~10dB ±1.0dB Custom: 11dB~25dB ±1.5dB
Maximum Power Capability	250mW
Operating Temperature	-40℃~+75℃

Note: Custom configurations available upon request

Overall Performance

Fiber optic attenuators are used in applications where a pre-determined amount of light loss is specified. We offer LC, FC, SC, ST, MU fixed attenuators with different attenuation levels from 1dB to 30dB.

Parameter	Specification
Attenuation Value	0dB to 30dB
Operating Wavelength	SM: 1260nm~1620nm, MM: 850/1300nm (Customer ordered)
Return Loss	UPC≥50dB, APC≥60dB
Polarization Loss	≤0.2dB
Attenuation Tolerance	0dB~9dB: 0.5dB, 10~30dB: 10% of attenuation value
Maximum Power Capability	250mW
Operating Temperature	-40°C~+85°C
Storage Temperature	-40°C~+85°C

Applications

Power management in optical networks
Wavelength division multiplexing (WDM) system channel balancing
Erbium Doped Fiber Amplifiers (EDFA)
Optical add-drop multiplexers (OADM)
Receiver protection
Test equipment
Compensation of different connector attenuation

Frequently Asked Questions

1. Are you the real factory?

Yes, we are the real factory with 16 years of manufacturing history.

2. What is your fiber brand?

Fiber brands including YOFC and FiberHome.

3. What are your main products?

Fiber optic patch panels, fiber MPO & MTP cassettes, MPO & MTP cables, outdoor fiber optic cables, indoor fiber optic cables, FTTH drop cables, ADSS cables, indoor armored patch cords, and optical patch cords (SC, LC, FC, ST, MTP, MPO).

4. Product quality guarantee period?

20 years guarantee for fiber optic cable.

5. Do you have certificate for raw material?

We build long-term relationship cooperation with qualified ISO9001 ROHS raw material suppliers.

6. What is your delivery time?

Within 48 hours for normal kinds of fiber optic products.

7. MOQ: what is your minimum quantity?

MOQ for Fiber Optic Cable Patch Panel: 10 sets. There is no MOQ required for fiber optic patch cords, as we maintain stock for normal kinds.

8. Do you have distributor in other country or domestic?

Until now we sell our products to customers directly and factory price can be offered.

9. Payment

For large orders: T/T. For small orders: T/T and Paypal are acceptable.

10. Shipping & Delivery

For large orders: by sea (LCL or FCL). For small orders: by sea (LCL), by air, or by courier services - any of which is optional.
