products details

Home > Products >

MPO MTP Cable

LSZH Jacket OM3 Multimode MPO Trunk Cable Female to 4 DX SC Fiber Optical Patch Cable

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

LSZH Jacket OM3 Multimode MPO Trunk Cable Female to 4 DX SC Fiber Optical Patch Cable

Brand Name:	New Light
Model Number:	MPO- SC
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Product Name:

MPO Trunk Cable MPO Female To 4 DX SC Multimode OM3 Fiber Optical Cable

Core Type:

Insertion Loss:

Insertion Loss ≤ 0.5dB

Fiber Type:

Multimode

Jacket:

Cable Diameter:

3.0mm

Cable Color:

MPO Type:

Female Type

Supply Ability:

500 pcs per day

Highlight:

LSZH MPO Trunk Cable

3.0mm MPO Trunk Cable

Multimode OM3 fiber patch cable

Product Description

LSZH MPO Trunk Cable Female To 4 DX SC Multimode OM3 Fiber Patch Cable

Product Overview

MPO Trunk Cable MPO Female To 4 DX SC Multimode OM3 Fiber Optical Cable is designed for interconnections between MTP/MPO cassettes or connections to active equipment with MPO/MTP interface. Suitable for use in 1U distribution frames.

Key Features

Quick, highly repeatable, low-loss connections
Simplex & Duplex configurations available
Singlemode & Multimode options
PC, UPC & APC polishing types
Various boot (cable) sizes available
FC/LC/SC/ST/MTR/MPO connectors available
Interferential parameters
Hybrid patch-cords available upon request
Low Insertion loss
Low PDL

Applications

LAN, WAN and Metro Networks
FTTH project & FTTX Deployments
CATV System
GPON, EPON
Fiber Optic Test Equipment
Data-base Transmit Broadband Net

Technical Specifications

Parameter	Specification
Product Name	MPO Trunk Cable MPO Female To 4 DX SC Multimode OM3 Fiber Optical Cable
Mode Type	MM (Multimode)
Cable Count	8 core (can be 4/8/12/16/24/32 core)
Core Type	50/125μm
Cable Color	Aqua (customizable)
Cable Diameter	3.0mm (customizable)
Outer Jacket Material	LSZH
Insertion Loss	≤ 0.5dB
Return Loss	≥25 dB
Wavelength	850/1300nm
Connector Type	Female
Connector Color	Aqua (Aqua/Magenta/Beige available)
Ferrule Material	Plastic
Operating Temperature	-40°C to +85°C
Warranty	3 years after delivery
Delivery Time	2-15 working days (depending on quantity)

Ordering Information

Connector type: SC/FC/LC/ST/MPO/MTP/MU/MTRJ/E2000/SMA
Mode type: Single mode (UPC and APC) / Multi mode (PC)
Cable diameter: 0.9/2.0/3.0mm (customizable)
Coating material: PVC/LSZH
Fiber count: Simplex/Duplex/4 core/6 core/8 core/12 core/24 core/48 core/96 core
Cable type: G652D/G657A1/G657A2/G655/OM1/OM2/OM3-150/OM3-300/OM4/OM5
Patch cord length: Customizable
MPO/MTP connector specifications: Method (A/B/C type), Male/Female, Fiber count (4/8/12/16/24/32 fiber)

Why Choose Us

On-time delivery
Customization services
Factory direct pricing
Large product inventory with massive production capacity
China's professional fiber optic solutions leader
Quality guarantee
Global product distribution across multiple industries

Frequently Asked Questions

Q: Are you a manufacturer?

A: Yes, we are a manufacturer located in Shenzhen, China.

Q: What's your MOQ?

A: MOQ can be 1 piece, but we don't recommend ordering single units due to higher costs. Larger quantities receive more competitive pricing.

Q: What's the price?

A: Pricing depends on quantity. We provide our best pricing based on your order volume, with significant discounts for larger quantities.

Q: Can you quote FOB price?

A: We can quote FOB prices, but due to the compact size and weight of our products, we typically ship via air carriers (DHL, TNT, UPS, FEDEX). We recommend providing your specifications and quantity for a complete shipping quote. EXW or CFR pricing may be more suitable for your needs.

Q: How is your quality?

A: Our production follows IEC and European standards in near dust-free workshop conditions. We use imported production and quality control equipment, with 100% product testing before delivery.

WhatsApp: +8613534063703

Tags:

mpo to mpo cable

mpo fiber cable

mpo fanout cable

Products Details

Home > Products >

MPO MTP Cable

LSZH Jacket OM3 Multimode MPO Trunk Cable Female to 4 DX SC Fiber Optical Patch Cable

All Category

Optical Fiber Patch Cord

MPO MTP Patch Cord

MPO MTP Cable

MPO Cassette Module

Fiber Optic Patch Panel

Fiber Optic Pigtail

FTTH Termination Box

Fiber Optic Connectors

Quick Assembly Connector

Fiber Optic Adapter

Fiber Optic Attenuator

Fiber Optic Loopback

Fiber Optic Cables

Fiber Optic Tools

Fiber Optic Transceiver

Fiber Optic Splitter

Fiber Optic WDM

Fiber Optic Splice Closure

Copper Patch Cords

Rj45 Patch Panel

RJ45 Ethernet Connector

Drone Fiber Optic

Switch And Socket

LSZH Jacket OM3 Multimode MPO Trunk Cable Female to 4 DX SC Fiber Optical Patch Cable

Brand Name:	New Light
Model Number:	MPO- SC
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Brand Name:

New Light

Certification:

CE , ISO , RoHS

Model Number:

MPO- SC

Product Name:

MPO Trunk Cable MPO Female To 4 DX SC Multimode OM3 Fiber Optical Cable

Core Type:

Om3

Insertion Loss:

Insertion Loss ≤ 0.5dB

Fiber Type:

Multimode

Jacket:

LSZH

Cable Diameter:

3.0mm

Cable Color:

Aqua

MPO Type:

Female Type

Minimum Order Quantity:

1~10000

Price:

6~15

Packaging Details:

OPP bag + carton box

Delivery Time:

2-7 working days ( according to your quantity )

Payment Terms:

T/T,Western Union,MoneyGram,paypal,MoneyGram

Supply Ability:

500 pcs per day

Highlight:

LSZH MPO Trunk Cable

3.0mm MPO Trunk Cable

Multimode OM3 fiber patch cable

Product Description

LSZH MPO Trunk Cable Female To 4 DX SC Multimode OM3 Fiber Patch Cable

Product Overview

Key Features

Quick, highly repeatable, low-loss connections
Simplex & Duplex configurations available
Singlemode & Multimode options
PC, UPC & APC polishing types
Various boot (cable) sizes available
FC/LC/SC/ST/MTR/MPO connectors available
Interferential parameters
Hybrid patch-cords available upon request
Low Insertion loss
Low PDL

Applications

LAN, WAN and Metro Networks
FTTH project & FTTX Deployments
CATV System
GPON, EPON
Fiber Optic Test Equipment
Data-base Transmit Broadband Net

Technical Specifications

Parameter	Specification
Product Name	MPO Trunk Cable MPO Female To 4 DX SC Multimode OM3 Fiber Optical Cable
Mode Type	MM (Multimode)
Cable Count	8 core (can be 4/8/12/16/24/32 core)
Core Type	50/125μm
Cable Color	Aqua (customizable)
Cable Diameter	3.0mm (customizable)
Outer Jacket Material	LSZH
Insertion Loss	≤ 0.5dB
Return Loss	≥25 dB
Wavelength	850/1300nm
Connector Type	Female
Connector Color	Aqua (Aqua/Magenta/Beige available)
Ferrule Material	Plastic
Operating Temperature	-40°C to +85°C
Warranty	3 years after delivery
Delivery Time	2-15 working days (depending on quantity)

Ordering Information

Connector type: SC/FC/LC/ST/MPO/MTP/MU/MTRJ/E2000/SMA
Mode type: Single mode (UPC and APC) / Multi mode (PC)
Cable diameter: 0.9/2.0/3.0mm (customizable)
Coating material: PVC/LSZH
Fiber count: Simplex/Duplex/4 core/6 core/8 core/12 core/24 core/48 core/96 core
Cable type: G652D/G657A1/G657A2/G655/OM1/OM2/OM3-150/OM3-300/OM4/OM5
Patch cord length: Customizable
MPO/MTP connector specifications: Method (A/B/C type), Male/Female, Fiber count (4/8/12/16/24/32 fiber)

Why Choose Us

On-time delivery
Customization services
Factory direct pricing
Large product inventory with massive production capacity
China's professional fiber optic solutions leader
Quality guarantee
Global product distribution across multiple industries

Frequently Asked Questions

Q: Are you a manufacturer?

A: Yes, we are a manufacturer located in Shenzhen, China.

Q: What's your MOQ?

A: MOQ can be 1 piece, but we don't recommend ordering single units due to higher costs. Larger quantities receive more competitive pricing.

Q: What's the price?

A: Pricing depends on quantity. We provide our best pricing based on your order volume, with significant discounts for larger quantities.

Q: Can you quote FOB price?

Q: How is your quality?

A: Our production follows IEC and European standards in near dust-free workshop conditions. We use imported production and quality control equipment, with 100% product testing before delivery.

WhatsApp: +8613534063703

Tags:
