Product Details:
|
| Cable Color: | Yellow | Connector Color: | Green |
|---|---|---|---|
| Connector Type: | LC | Polish: | APC |
| Cable Length: | Customised | OEM: | Available |
| Highlight: | mpo fiber cable,mpo to mpo cable |
||
Quick Details
* Model Number: MPO
* Number of Conductors: ≥ 10
* Outdoor Jacket material::LSZH,OFNP,OFNR
* Fiber Count:: 8/12/24/36/48/72/96/144
* Labeling:: Standard or Customize
* Breakout Length First&Second(inches)::12-99(36" is typical)
* Termination:: FIRST END(MPO/MTP) SECOND END(MPO/MTP/FC/SC/LC/ST..)
* Cable length:: 1-999
* Fiber type:: OS2/OM1/OM2/OM3/OM4
Details:
Connector End face: MPO end face geometry requirements: EN50377-15-1
Polishing Quality:: Polished end-face quality: IEC61300-3-35
Our MPO patch cables are designed for data center solutions supporting the topologies such as 10
Gigabit Ethernet, Fiber Channel or Infiniband - as specified in the data center standards EN50173-5 and
ISO/IEC 24764.
Performance of Assemblies MTP / MPO Termination:
| Type/Performance | Singlemode(APC polish) | Multimode(PC / Flat Polish) | ||
| Standard | Elite Low Loss | Standard | Elite Low Loss | |
| Maximum Insertion Loss | ≤ 0.75dB | ≤ 0.35dB | ≤ 0.60dB | ≤ 0.35dB |
| Return Loss | ≥ 50dB | N/A | ||
| Operating Temperature | -40°C to 80°C | 40°C to 80°C | ||
| Test Wavelength | 1310nm | 850nm |
||
