12 Core OM4 MPO MTP Cable for 40/100G Networks with MPO to LC Breakout

Brand Name:	New Light
Model Number:	MPO / MTP - MPO / MTP
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Name:

MPO MTP Cable

Material:

LSZH, OFNP Or OFNR

Mode Type:

Core Type:

12 Core

Delivery Time:

2-7 Working Days After Received Deposit

Production Ability:

500 Pcs / Day

Payment Term:

T/T , 30% Deposit In Advance

Connector:

MPO,MTP

Color:

Aqua,orange,yellow,Yellow/ Red/ Aqua

Supply Ability:

500 pcs per day

Highlight:

mpo fiber cable

mpo to mpo cable

Product Description

MTP/MPO Fiber Connector Fanout Cable - 40G/100G MTP to LC Breakout Cable

Independent verification and tests have continually reinforced the MTP connector as offering superior over-life performance when compared to standard MPO connectors. This higher performance has resulted in wide adoption by fiber cabling manufacturers, as well as switch, server and storage manufacturers.

MPO MTP Cable Overview

New Light 40G parallel networks are created by combining MPO trunk cables and MPO patch cables via MPO adapter modules. Direct connection between two 40G or 100G ports can also be made using the same MPO patch cable.

Typically, these cables use an MPO 12-fiber connector and 12-fiber cable. While SR4 40G or 100G Ethernet only uses 8 fibers, the advantage of 12-fiber cables is their compatibility with duplex 10G networking, offering greater flexibility with negligible cost difference.

MPO MTP Cable Applications

Multimode (OM3 or OM4 50/125) Fiber Applications:

Connect directly between two QSFP+ transceivers for 40GBase-SR4
Connect directly between two QSFP28 transceivers for 100GBase-SR4
Connect to MPO trunk cables

Singlemode (OS1 or OS2 9/125) Fiber Applications:

Connect directly between two QSFP+ PLR4 (LR4 PSM) transceivers for 40G Ethernet
Connect directly between two QSFP28 PLR4 (LR4 PSM) transceivers for 100G Ethernet
Connect to MPO trunk cables

Both multimode and singlemode patch cords typically feature polarity B and female connectors.

MPO MTP Cable Features

US Conec MTP connector, Senko MPO Plus premium connector
OS2, OM3, OM4 fiber grades (OM1 and OM2 available)
0.35dB Elite low loss MTP/MPO connector as well as standard versions of 0.6/0.75dB
Factory terminated and tested
Allow easy migration from 10GbE to 40GbE or 100GbE
Pulling eyes available as an option to protect fiber ends during installation

Technical Parameters

Item	Technical Parameters
Connector	MPO/MTP (F or M)
Operation Temperature	-40°C ~ +80°C
Storage Temperature	-40°C ~ +85°C
Insertion Loss	SM: ≤ 0.75dB (standard), ≤0.35dB (typical); MM: ≤ 0.50dB (standard), ≤0.35dB (typical)
Return Loss	SM: ≥60dB; MM: ≥35dB
MPO End Type	Male: with guide pin; Female: without guide pin
Fiber Count	8, 12 & 24 fiber
Connector Type (Other End)	MPO-female, MPO-male, FC, SC, ST, MU, LC, E2000
Fiber Mode	Single-mode (G652,G655,G657), multi-mode (50, 62.5, OM2, OM3, OM4)
Fiber Cable Type	250um ribbon fiber, ribbon cable, Bundle fiber optic cable

The three polarity methods Type A, Type B and Type C are used to guarantee the right bi-directional allocation.

Packaging

Products are packaged in OPP bags and carton boxes to ensure protection during delivery.

WHATSAPP: +8613534063703

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer located in Shenzhen, China.

What's your MOQ?

MOQ can be 1 piece, but we recommend larger quantities for better pricing.

What's the price?

Pricing is based on quantity. We offer competitive pricing for larger orders.

Can you quote FOB price?

Yes, but due to product size, air freight (DHL, TNT, UPS, FEDEX) is typically used. EXW or CFR pricing is often more suitable.

How is your quality?

We produce according to IEC and European standards in near dust-free workshops with imported production and quality control equipment. All products are 100% tested before delivery.

What's your lead time?

We have three factories in China. For fiber optic patch cords, lead time is 2-3 working days for 5000 pieces. Regular products are available from stock.

What's your warranty?

Patch cords have a 2-year warranty for non-artificial damage from delivery date.

What's your packing?

We use international export packaging and can print your logo on packaging.

Can you do OEM/ODM?

Yes, we accept OEM/ODM and can sign confidentiality agreements.

Can I have a sample?

Free samples available for adaptors, attenuators, patch cords, and pigtails (freight paid by customer). For high-value products, sample charges apply but are refundable with orders.

How can I order?

Send requirements including product name, specifications, and quantity. We'll provide pricing and lead time, then issue proforma invoice upon acceptance.

What are your payment terms?

T/T, Western Union, Paypal, MoneyGram. For large amounts: 50% deposit, 50% balance before delivery.
