0.9mm Multimode ST Fiber Optic Connector for Local Area Networks with ROHS Compliance

Brand Name:	New Light
MOQ:	100
Price:	0.1~100
Packaging Details:	1 pcs per pack
Payment Terms:	T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

RoSH

Name:

ST Fiber Optic Connector

Color:

Black

Material:

Plastic,Metal

Connector:

Model:

Multimode

OEM:

Available

Supply Ability:

10000 pcs per week

Highlight:

fiber optic cable connectors

multimode fiber connectors

Product Description

ST Multimode Fiber Connectors

0.9mm Fiber Optic ST Connector For Local Area Networks

Quick Specifications

Model Number	ST
Singlemode / Multimode	SM / MM
Simplex / Duplex	SX / DX
Boot Size	0.9mm / 2mm / 3mm
Aqua Compatibility	OM3, OM3+, OM4 PC

Key Features

ST Connector compatibility
Fast Ethernet support
ATM networks and Optical Access network
Free samples available with fast delivery
ROHS compliant

Product Introduction

Optichina Connectors deliver superior performance with exceptional repeatability. Our products are fully compatible with NTT equipment and provide long-term stability across diverse applications and environmental conditions. Featuring pre-radiused Zirconia Ferrules for optimal low-loss performance.

Technical Features

Superior qualified standard polishing
100% optical testing: Insertion Loss ≤0.3dB (PC); ≤0.2dB (APC); ≤0.2dB (UPC); ≤0.3dB (SPC)
100% optical testing: Return Loss ≥45dB (PC); ≥60dB (APC); ≥55dB (UPC); ≥50dB (SPC)
Cable options: φ0.9mm, φ2.0mm, φ3.0mm
Simplex and duplex connector configurations available
Excellent exchange ability and durability
Available in fiber bunch, ribbon fan-out, and pigtail formats
Compliant with ISO9001, ROHS and Bell core GR 326-core standards
Custom specifications welcomed

Applications

CATV and metro test equipment; FTTH
Telecommunication networks
Local area networks (LAN)
Wide area networks (WAN)
Premise installations
Data processing networks
Video and military active device termination
Optical Distribution Frame
Optical Network Equipment
