ST Multimode Fiber Connectors , 0.9mm Fiber Optic ST Connector For Local Area Networks

Multimode ST 0.9mm ptical Fiber Connectors For Local area networks

Qucik Detail:

Model Number:ST

Singlemode / Multimode: SM / MM

Simplex / Duplex: SX / DX

Boot Size:: 0.9mm / 2mm / 3mm

Aqua: OM3, OM3+, OM4 PC

Detailed:

1. ST Connector

2. Fast Ethernet
3. ATM networks and Optical Access network
4. Free Sample & Fast delivery time

5. ROHS

Product Introduction:

Optichina Connectors offer superior performance with very high repeatability and our products are fully interactive with NTT products and deliver long term stability under a wide range of applications and conditions. Our product utilizes pre-radiused Zirconia Ferrules for low loss.

Features:

1) Superior qualified standard polishing;
2) 100% optic test: Insertion Loss: ≤0.3 (PC); ≤0.2 (APC); ≤0.2 (UPC); ≤0.3 (SPC);

3) 100% optic test: Return Loss: ≥45 (PC); ≥60 (APC); ≥55 (UPC); ≥50 (SPC);

4) φ0.9mm, φ2.0mm, φ3.0mm cable optional

5) Simplex and duplex connector available;

6) Good exchange ability and good durability;

7) Available in fiber bunch, ribbon fan-out, pigtail available;

8) Meets ISO9001, ROHS and Bell core GR 326-core standards;

9) Customized specifications are welcomed.

Applications:

1) CATV, metro test equipment; FTTH;

2) Telecommunication networks;

3) Local area networks (LAN);

4) Wide area networks (WAN);

5) Premise installations;

6) Data processing networks;

7) Video and military active device termination.

8) Optical Distribution Frame

9)Optical Network Equipments
