Ceramic Fiber Optic Ferrule with SC/APC Connector for Low Insertion Loss and High Return Loss

Brand Name:	New Light
MOQ:	100
Price:	0.1~100
Packaging Details:	1 pcs per pack
Payment Terms:	T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Brand Name:

New Light

Certification:

RoSH

Name:

Fiber Optic Ceramic Ferrule

Color:

White

Material:

Ceramic

Connector Type:

Polish:

APC

OEM:

Available

Minimum Order Quantity:

100

Price:

0.1~100

Packaging Details:

1 pcs per pack

Delivery Time:

7 working days

Payment Terms:

T/T,Western Union,MoneyGram

Supply Ability:

10000 pcs per week

Highlight:

fiber optic parts and accessories

fiber optic cable assembly

Product Description

CATV Fiber Optic Cable Assembly, Fiber Optic Accessories SC/APC Step Ferrule

High-performance fiber optic cable assembly and accessories designed for precision connectivity in demanding applications.

Applications

CATV Systems
Telecom Networks
Optical Test Equipment
Local Area Networks
Wide Area Networks
Data Processing Networks

Key Features

Excellent materials for superior performance
Good compatibility with existing systems
High reliability and stability
Precise dimensional accuracy
Low insertion loss and high return loss
High intensity with excellent anti-erosion and anti-aging properties

Technical Specifications

Parameter	SC/PC Series	SC/APC Series	LC/MU Series
Length	10.50±0.01mm	10.50±0.01mm	6.50±0.01mm
Outer Diameter	2.4990±0.0005mm	2.4990±0.0005mm	1.4990±0.0005mm
Inner Diameter	0.125~0.128mm	0.125~0.126mm	0.125~0.128mm
Concentricity	≤1um, ≤3um	≤0.5um, ≤1um	≤1um, ≤3um
Endface Type	Spherical Surface	Step or Conical	Spherical Surface
