High Precision SC/PC Ceramic Ferrule with Low Insertion Loss and High Return Loss for Fiber Optic Connectors

Brand Name:	New Light
MOQ:	100
Price:	0.1~100
Packaging Details:	1 pcs per pack
Payment Terms:	T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Brand Name:

New Light

Certification:

RoSH

Name:

Fiber Optic Ceramic Ferrule

Color:

White

Connector Type:

Polish:

APC

Material:

Ceramic

OEM:

Available

Minimum Order Quantity:

100

Price:

0.1~100

Packaging Details:

1 pcs per pack

Delivery Time:

7 working days

Payment Terms:

T/T,Western Union,MoneyGram

Supply Ability:

10000 pcs per week

Highlight:

fiber optic accessories

fiber optic cable assembly

Product Description

High Precise Dimension Fiber Optic Parts SC / PC Ceramic Ferrules Fiber Optics

Applications

CATV Systems
Telecom Networks
Optical Test Equipment
Local Area Networks (LAN)
Wide Area Networks (WAN)
Data Processing Networks

Product Features

Premium Material Construction
Excellent Compatibility
High Reliability and Stability
Precise Dimensional Accuracy
Low Insertion Loss with High Return Loss
Superior Strength with Anti-Erosion and Anti-Aging Performance

Technical Specifications

Parameter	SC/PC Series	SC/APC Series	LC/MU Series
Length	10.50±0.01mm	10.50±0.01mm	6.50±0.01mm
Outer Diameter	2.4990±0.0005mm	2.4990±0.0005mm	1.4990±0.0005mm
Inner Diameter	0.125~0.128mm	0.125~0.126mm	0.125~0.128mm
Concentricity	≤1μm, ≤3μm	≤0.5μm, ≤1μm	≤1μm, ≤3μm
Endface Type	Spherical Surface	Step or Conical	Spherical Surface
