Single Mode SC UPC MINI PLC 1x2 Fiber Optic Splitter for High-Density Output Applications

Brand Name:	New Light
MOQ:	10
Price:	1~30
Packaging Details:	export packing
Payment Terms:	Western Union,T/T,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Color:

Yellow Cable,blue Connector

Connector Type:

Polish:

UPC

Splitter:

1x2

Mode:

Single Mode

OEM:

Available

Supply Ability:

1000000

Highlight:

fiber optic plc splitter

single mode fiber splitter

Product Description

Fiber Optic Cable Splitter, Single Mode SC UPC MINI PLC 1x2 PLC Splitter

SC UPC MINI PLC 1X 2 Single mode SC splitter fiber optic 1x2 SC pc plc splitter

Product Features

Basic type PLC splitter
SFF type PLC splitter
900um Fan-out Type PLC Splitter
Cassette type PLC splitter Module
Rack type PLC splitter Module
Tray assembly PLC splitter Module
Flat Quick-Connect Termination Type PLC Splitter Module

Technical Specifications

Parameters	1x4	1x8	1x16	1x32	1x64
Operating Wavelength(nm)	1260-1650
Insertion Loss (dB) Max(S/P)	7.4/7.2	10.7/10.5	13.7/13.5	16.9/16.5	21
Loss Uniformity (dB) Max	0.6	0.8	1.2	1.7	2.5
Return Loss (dB) Min(S/P)	50/55	50/55	50/55	50/55	50
PDL (dB) Max	0.2	0.3	0.3	0.3	0.4
Directivity (dB) Min	55	55	55	55	55
Pigtail Length(m)	1.2(±0.1) or customer specified
Fiber Type	SMF-28e or customer specified
Wavelength Dependent Loss(dB)	1	1	1	1	1
Temperature Stability (-40~85 ℃)(dB)	0.6	0.6	0.8	1	1
Operating Temperature( ℃)	-20~75
Storage Temperature( ℃)	-40~85
Packaging Size(L x W x H)(mm)	40x4x4	40x4x4	40x4x4	50x7x4	60x12x4

Product Overview

Single Mode PLC Steel Tube type Fiber Optic Splitter (PLC Splitter) provides accurate splitting in high-density output configurations (such as 8, 16, 32, 64 outputs). The most common type of fiber optic splitter evenly distributes output signals, delivering consistent light signal transmission. Due to its exceptional performance, optical splitters are essential components in passive optical networks (PON).

Applications

Fiber to the point (FTTX)
Fiber to the home (FTTH)
Passive optical networks (PON)
Local area networks (LAN)
Cable television (CATV)
Test equipment
