High-performance simplex single mode fiber optic patch cord with 0.9mm TPEE material construction in green color, designed for telecommunications applications.

Fiber Specifications

Material	OS1 9/125μm (1310/1550nm)	OM1 62.5/125μm (850/1300nm)	OM2 50/125μm (850/1300nm)	OM3 50/125μm (850/1300nm)
Attenuation (dB/km) Typical Values	0.4/0.3	3.5/1.5	3.5/1.5	2.7/0.7
Minimum Bandwidth (MHz•km)	N/A	400/400	160/500	1500/500
Primary Buffer Diameter	250μm	250μm	250μm	250μm

Cable Construction

Strength Members: 4x1320 Decitex Kevlar element
Storage / Operating / Installation Temperature: -20℃ to +60℃
Sheath material: PVC or LSZH Sheath

Fiber Optic Cable Specifications

Fiber Count	2	4	6	8	12	16	24
Nominal Outer Diameter (mm)	5.0±0.2	5.1±0.2	5.3±0.2	5.9±0.2	6.6±0.2	7.5±0.2	8.2±0.2
Nominal Weight (kg/km)	19	21	23	28	34	46	57

Maximum Tensile Load:
Long Term: 220N
Short Term: 660N

Key Features

High strength aramid yarn strength member ensures high tensile strength and long-term transmission stability
Small outer diameter, lightweight, flame-retardant, easy to strip, low attenuation, physically soft
Direct splicing between tight buffer cables with no tie-in box or pigtail required
Suitable for installation, operation, and convenient for maintenance

Color Identification

Single-mode cable: yellow; Multi-mode cable: orange; Custom colors, LSZH or flame-retardant materials available upon request

Tags:

fiber optic pigtail

ftth fiber optic cable

single mode fiber jumpers

Products Details

Home > Products >

Fiber Optic Cables

Simplex Single Mode Fiber Optic Patch Cord with 0.9mm Outer Diameter and Green Color for Telecommunication

All Category

Optical Fiber Patch Cord

MPO MTP Patch Cord

MPO MTP Cable

MPO Cassette Module

Fiber Optic Patch Panel

Fiber Optic Pigtail

FTTH Termination Box

Fiber Optic Connectors

Quick Assembly Connector

Fiber Optic Adapter

Fiber Optic Attenuator

Fiber Optic Loopback

Fiber Optic Cables

Fiber Optic Tools

Fiber Optic Transceiver

Fiber Optic Splitter

Fiber Optic WDM

Fiber Optic Splice Closure

Copper Patch Cords

Rj45 Patch Panel

RJ45 Ethernet Connector

Drone Fiber Optic

Switch And Socket

Simplex Single Mode Fiber Optic Patch Cord with 0.9mm Outer Diameter and Green Color for Telecommunication

Brand Name:	New Light
MOQ:	1 roll
Price:	0.1~100
Packaging Details:	export packing
Payment Terms:	T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Brand Name:

New Light

Certification:

ISO ,ROSH

Name:

Single Mode Fiber Optic Cable

Fiber Type:

Simplex

Color:

Green

Outer Diameter:

0.9mm

Material:

TPEE

OEM:

Available

Minimum Order Quantity:

1 roll

Price:

0.1~100

Packaging Details:

export packing

Delivery Time:

7 working days

Payment Terms:

T/T,Western Union,MoneyGram

Supply Ability:

1000000

Highlight:

duplex fiber optic patch cable

fiber optic drop cable
