OEM 12 Port 19 Inch Fiber Optic Patch Panel Optical Fiber Distribution Frame for CATV Applications

Brand Name:	New Light
MOQ:	1~10000
Price:	10~100
Packaging Details:	1 piece per pack
Payment Terms:	T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Color:

Black

Core Number:

Application:

FTTX, FTTH Odf

Fiber:

Simplex,Duplex

Name:

Outdoor Fiber Optic Patch Panel

OEM:

Available

Supply Ability:

1000 pcs per month

Highlight:

odf optical fiber distribution frame

odf fiber optic patch panel

Product Description

OEM 12 Port Fiber Optic Patch Panel for CATV Applications

19-inch standard 12-core ODF optical fiber distribution frame designed specifically for CATV systems, providing reliable fiber optic connectivity and management.

Key Features

19" standard rack size for easy installation
Lightweight construction with high strength and excellent anti-shock performance
Superior dustproof protection for long-term reliability
Well-organized cable management system for easy identification
Spacious interior ensures proper fiber bend radius
Removable adapter fence for flexible configuration

Performance Specifications

Maximum Capacity: 4-96 ports, 4 fibers per port
Available Adapter Ports: ST, FC, SC, LC, MU, MTRJ
Panel Compatibility: Various panels available to fit different adapter interfaces
Weight: 2.3kg

Technical Specifications

Type: Cable installation, wall mount
Available Sizes: 40×38×14cm, 30×30×8.5cm, 40.5×38.2×8.5cm
Capacity: 12 SC, 12 LC
Connector Options: SC, SC/APC, LC, LC/APC, ST, FC

Applications

Telecommunications subscriber loop systems
Fiber to the home (FTTH) deployments
LAN/WAN network infrastructure
CATV and broadband distribution networks

Electrical Performance

Parameter	Specification
Environment Temperature	-25°C to 55°C
Atmosphere Pressure	70-106 Kpa
Insulating Resistance	>2×10⁴ MΩ/500VDC
Relative Humidity	<85% (when temperature is below 30°C)
Voltage Strength	15kV/DC/1min, non-puncture, no arc-over

WHATSAPP 008613534063703
