Parameter	Options
Connector type	SC, FC, ST, LC, E2000, DIN, MU, MTRJ, etc.
Polish	UPC, APC, PC
Cable type	Simplex, Duplex straight, Duplex Reverse
Fiber	SM(G652), 62.5/125um, 50/125um, OM2, OM3, SM(G655)
Cable Jacket	Riser, Plenum, LSZH
Cable Diameter	3.0mm, 2.0mm, 0.9mm, etc.
Cable Length	Custom length in meters

Product Specifications

Parameter	Specification	Parameter	Specification
Connector	E2000 to E2000	Jacket OD	3.0mm
Fiber Mode	9/125µm	Jacket Color	Yellow
Polish	APC to APC	Wavelength	1310/1550nm
Fiber Type	Simplex	Jacket Material	PVC
Insertion loss	≤0.3dB	Interchangeability	≤0.2dB
Return loss	≥50dB	Vibration	≤0.2dB
Operating temperature	-40~70℃	Storage temperature	-45~85℃
Polarity	A(Tx) to B(Rx)	Fiber Grade	G652D

Tags:

fiber optic pigtail

ftth fiber optic cable

single mode fiber jumpers

Products Details

Home > Products >

Fiber Optic Cables

1.5Meter 2.0mm Diameter Fiber Optic Patch Cord with E2000/APC Connector and PVC Jacket

All Category

Optical Fiber Patch Cord

MPO MTP Patch Cord

MPO MTP Cable

MPO Cassette Module

Fiber Optic Patch Panel

Fiber Optic Pigtail

FTTH Termination Box

Fiber Optic Connectors

Quick Assembly Connector

Fiber Optic Adapter

Fiber Optic Attenuator

Fiber Optic Loopback

Fiber Optic Cables

Fiber Optic Tools

Fiber Optic Transceiver

Fiber Optic Splitter

Fiber Optic WDM

Fiber Optic Splice Closure

Copper Patch Cords

Rj45 Patch Panel

RJ45 Ethernet Connector

Drone Fiber Optic

Switch And Socket

1.5Meter 2.0mm Diameter Fiber Optic Patch Cord with E2000/APC Connector and PVC Jacket

Brand Name:	NewLight
MOQ:	1 roll
Price:	0.1~100
Packaging Details:	export packing
Payment Terms:	T/T,Western Union,MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Brand Name:

NewLight

Certification:

ISO ,ROSH

Name:

E2000 - E2000 Patch Cord

Diameter:

2.0mm

Fiber Type:

Simplex

Connector:

E2000-E2000

Color:

Yellow

Length:

3 Meter

Minimum Order Quantity:

1 roll

Price:

0.1~100

Packaging Details:

export packing

Delivery Time:

7 working days

Payment Terms:

T/T,Western Union,MoneyGram,Paypal

Supply Ability:

1000000

Highlight:

fiber optic pigtail

single mode fiber jumpers

Product Description

1.5Meter 2.0 Mm Diameter Fiber Optic Jumper Cables E2000/APC With PVC Jacket

1.5Meter 2.0 mm diameter PVC Jacket Fiber Optic patch cord E2000/APC single model simplex

Key Features

Low insertion loss, back reflection & high return loss
UL-rated plastic housing and boots in a variety of colors
Push-pull design provides excellent mechanism endurance
High quality ceramic ferrules
High credibility and stability with good repeatability and exchangeability
Compliance with ROHS requirements

Applications

CATV systems
Telecommunication networks
Wide Area Networks
Industrial, medical & military applications
Local Area Networks
Test equipment
Active device termination
Data processing networks

Available Options & Ordering

Full specifications: FC, SC, ST, LC, MTRJ, etc.
Simplex and Duplex assemblies available
Singlemode and multimode options
PC, UPC and APC polishing available
PVC and LSZH outer sheath materials
0.9mm, 2.0mm and 3.0mm cable sizes
Hybrid patch cords available upon request
Fan-out available (Ribbon/bundle)
Pigtail available
Loopback available
Customized lengths

Ordering Specifications

Parameter	Options
Connector type	SC, FC, ST, LC, E2000, DIN, MU, MTRJ, etc.
Polish	UPC, APC, PC
Cable type	Simplex, Duplex straight, Duplex Reverse
Fiber	SM(G652), 62.5/125um, 50/125um, OM2, OM3, SM(G655)
Cable Jacket	Riser, Plenum, LSZH
Cable Diameter	3.0mm, 2.0mm, 0.9mm, etc.
Cable Length	Custom length in meters

Product Specifications

Parameter	Specification	Parameter	Specification
Connector	E2000 to E2000	Jacket OD	3.0mm
Fiber Mode	9/125µm	Jacket Color	Yellow
Polish	APC to APC	Wavelength	1310/1550nm
Fiber Type	Simplex	Jacket Material	PVC
Insertion loss	≤0.3dB	Interchangeability	≤0.2dB
Return loss	≥50dB	Vibration	≤0.2dB
Operating temperature	-40~70℃	Storage temperature	-45~85℃
Polarity	A(Tx) to B(Rx)	Fiber Grade	G652D
