Single Mode LC-LC Fiber Patch Cord 3.0mm Diameter for FTTX Applications

Brand Name:	NewLight
MOQ:	1~100000
Price:	0.1~100
Packaging Details:	1 pcs per pack
Payment Terms:	T/T,Western Union,MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Name:

LC-LC Fiber Patch Cord

Diameter:

3.0mm

Model:

Singlemode

Connector:

LC-LC

Color:

Blue

Length:

3 Meters

Supply Ability:

1000000

Highlight:

duplex fiber patch cord

single mode fiber optic cable

Product Description

3M LC/UPC - LC/UPC Optical Fiber Patch Cord Single Mode for FTTX Applications

This 3M LC/UPC-LC/UPC OM3 Duplex single mode fiber optic patch cord cable is designed for optic-fiber access networks and delivers reliable performance in demanding applications.

Product Overview

Optical fiber patch cords are lengths of optical cable with connectors fixed on both ends to enable active optical path connections. Pigtails feature a single connector on one end. Hybrid patch cords have different connector types or end-faces on each side. These components are categorized by transmission medium (Single Mode or Multi Mode), connector structure (FC, SC, ST, MU, D4, LC), and polished ceramic end-face type (PC, UPC, APC).

Key Features

Low Insertion Loss
High Return Loss
Good Repeatability
Good Exchangeability
High Temperature Stability

Applications

Optic-fiber Communication Systems
Optic-fiber Data Communications
Optic-fiber Access Networks
Optic-fiber CATV
LAN, Cabling System, ODF
Test Equipment
Optic-fiber Sensors
FTTX Applications

Technical Specifications

Parameter	Specification
Style	LC, SC, ST, FC, MU, MPO, SC/APC, FC/APC, LC/APC, MU/APC Simplex/Duplex MTRJ/Female, MTRJ/Male
Fiber Type	9/125 SMF-28 or equivalent (Singlemode) OS1 50/125, 62.5/125 (Multimode) OM2 & OM1 50/125, 10G (Multimode) OM3
Cable Type	Simplex, Duplex (Zipcord) Φ3.0mm, Φ2.0mm, Φ1.8mm, Φ1.6mm PVC or LSZH Φ0.9mm, Φ0.6mm buffered fiber PVC or LSZH
Polishing Manner	UPC, SPC, APC (8° & 6°)
Insertion Loss	≤ 0.1dB (For Singlemode Master) ≤ 0.25dB (For Singlemode Standard) ≤ 0.25dB (For Multimode)
Return Loss (Singlemode)	UPC ≥ 50dB, SPC ≥ 55dB, APC ≥ 60dB (typ.65dB)
Repeatability	±0.1dB
Operating Temperature	-40°C to 85°C

Product Parameters

Connector: LC to LC

Fiber Mode: 9/125µm

Polish: UPC to UPC

Fiber Type: Simplex

Insertion Loss: ≤0.3dB

Return Loss: ≥50dB

Operating Temperature: -40~75℃

Polarity: A(Tx) to B(Rx)

Jacket OD: 3.0mm

Jacket Color: Blue

Wavelength: 1310/1550nm

Jacket Material: PVC

Interchangeability: ≤0.2dB

Vibration: ≤0.2dB

Storage Temperature: -45~85℃

Fiber Grade: G652D
