SC-SC Duplex OM4 Optical Fiber Patch Cord for High-Speed Data Transmission

Brand Name:	New Light
Model Number:	LC /FC /SC/ST / MPO / MTP/ MU / MTRJ
MOQ:	1~100000
Price:	0.1~100
Packaging Details:	OPP bag + carton box
Payment Terms:	L/C,T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Connector Type:

LC /FC /SC/ST / MPO / MTP/ MU / MTRJ

Fiber Type:

OM1 /OM2/OM3/OM4

Mode:

Multi Mode

Core Type:

Simplex / Duplex / 4 / 6/8/12/24/48 Core

Cable Diameter:

0.9/2.0/3.0 Mm

Cable Length:

Can Be Customized

Delivery Time:

2-7 Working Days After Receive Payment

Packing:

OPP Bag + Carton Box

Jacket Material:

PVC / LSZH

OEM/ODM:

Acceptable

Supply Ability:

1000000

Highlight:

sc sc fiber patch cord

single mode fiber optic cable

Product Description

SC-SC Multi Mode Optical Fiber Patch Cord Duplex

OM4 50/125 fiber optic patch cord with red/black boot connectors, designed for high-performance network applications.

Applications

Widely used in various optical network solutions including Security systems, WAN, LAN, CATV, FTTX, and Test Equipment applications.

Product Overview

Fiber Optic Patch Cords are pre-terminated fiber cables with connectors on both ends for active optical path connections. Pigtails feature a connector on one end only. Hybrid patch cords combine different connector types or end-faces.

Classification

Transmission Medium: Single Mode and Multi Mode
Connector Types: LC, FC, SC, ST, MU, MPO/MTP, E2000
End-face Polish: PC, UPC, and APC

Key Features

Screw-thread coupling mechanism
Ceramic ferrules for durability
Low insertion loss and high return loss
Excellent repeatability and exchangeability
100% tested for insertion loss, return loss, end face, and interference
Superior mechanical endurance
High reliability and stability

Compliance Standards

Complies with Telcordia GR-326-Core, IEC, and RoHS standards

Product Specifications

Structure Details

Connector Type: SC/PC Multi mode
Fiber Type: Φ3.0mm, OM4
Jacket Material: PVC
Color: Magenta
Length: Customizable to requirements

Technical Parameters

Parameter	Standard Fiber Cable Assemblies
Fiber Type	SM(G.652/G.657A) \| MM(OM1/OM2/OM3/OM4/OM5)
Jacket Materials	LSZH/OFNR/PVC
Connector Type	SC/LC/ST/LC/MU/DIN/SMA/MTRJ/MPO/E2000
Ferrule Materials	Ceramic
Testing Wavelengths	1310±30/1550±30nm \| 850±30/1300±30nm
Insertion Loss(dB)	≤ 0.25dB(PC/UPC/APC) \| ≤ 0.3dB(PC/UPC)
Return Loss(dB)	≥50dB(PC/UPC) ≥60dB(APC) \| ≥40dB(PC/UPC)
Exchangeability	≤ 0.2dB
Cable Assemblies	Pigtail/Simplex/Duplex/Fan-out Patchcord
Operating Temperature (°C)	-10 to +70
Storage Temperature (°C)	-40 to +85
Package	1 unit/bag

*All values specified are with connectors

Available Options

Connector Types	SC, ST, FC, LC, MU, MTRJ, E2000, MPO/MTP, SMA
Cables	PVC/LSZH, OM1, OM2, OM3, OM4, Plenum(OFNP), Armored
Colors	Yellow, gray, sky blue, orange, white, black

Packaging & Shipping

Packaging: Bags & carton boxes
Shipping Methods: International Express via FedEx, DHL, UPS, TNT and EMS
Custom Carriers: Available upon request with advance notification
FedEx Overnight: 1-3 business days delivery
DHL: 2-4 business days delivery (longer for Spain, Italy, Brazil due to customs)

Customer Service

Dedicated Support

"One to one" personalized service with sales representatives serving only five clients each to ensure focused attention and long-term partnership.

Comprehensive After-Sales

24-hour support through designated telephone numbers, email, and dedicated customer managers.
