Fiber Optic Splitter

SC PC Mini Fiber Optic Splitter Single Mode Low Insertion Loss for FTTH and CATV Applications

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

SC PC Mini Fiber Optic Splitter Single Mode Low Insertion Loss for FTTH and CATV Applications

Brand Name:	New Light
Model Number:	LC / FC / SC / ST / E2000
MOQ:	10
Price:	1~30
Packaging Details:	export packing
Payment Terms:	L/C,T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Brand Name:

New Light

Fiber Type:

0.9 /2.0 / 3.0 Mm

Connector Type:

LC / FC / SC / ST / E2000

Core Type:

SC PC

Operating Wave:

1260-1650

Mode Type:

Single Mode

OEM / ODM:

Acceptable

Fiber Length:

As Your Requirement

Warranty:

3 Years

Delivery Time:

2-10 Working Days After Receive Payment

Payment:

T/T , L/C , Paypal , Westen Union , Money Gram

Products Name:

SC PC MINI Splitter Fiber Optic Splitter PLC For FTTH / CATV Application

Supply Ability:

1000000

Highlight:

single mode fiber splitter

fiber optic cable splitter

Product Description

SC PC MINI Fiber Optic Splitter

Single Mode Low Insertion Loss PLC Splitter for FTTH and CATV Applications

Product Overview

900um FTTH Optic Fiber 1x2 Mini Module PLC Splitter. PLC Splitter is an integrated wave guide optical power distribution device based on quartz substrate, featuring small volume and wide operating beam split capabilities. Suitable for connecting in the local side and terminal of passive optical networks (EPON, BPON, GPON) to realize optical signal splitting.

Key Features

High strength stainless steel construction, passes salt spray test
Ferrule core less than 0.5um
100% new raw material, ROHS compliant
Low insertion loss
Low PDL compact design
Excellent channel-to-channel uniformity
Wide operating wavelength: 1260nm to 1650nm
Wide operating temperature: -40℃ to 85℃

Technical Specifications

Parameter	4 Channel	8 Channel	16 Channel
Channel Wavelength (nm)	1270-1610
Center Wavelength Accuracy (nm)	±0.5
Channel Spacing (nm)	20
Channel Pass Band (@-0.5dB bandwidth nm)	>14
Insertion Loss (dB)	≤1.4	≤2.6	≤5.0
Channel Uniformity (dB)	≤0.5	≤0.5	≤0.5
Channel Ripple (dB)	0.3
Isolation (dB) - Adjacent	>30	>30	>30
Isolation (dB) - Non-adjacent	>40	>40	>40
Insertion Loss Temperature Sensitivity (dB/℃)	<0.005
Wavelength Temperature Shifting (nm/℃)	<0.002
Polarization Dependent Loss (dB)	<0.1
Polarization Mode Dispersion (PS)	<0.1
Directivity (dB)	>50
Return Loss (dB)	>45
Maximum Power Handling (mW)	500
Operating Temperature (℃)	-5 to +75
Storage Temperature (℃)	-40 to 85

Package dimensions: L100 x W80 x H10 (2CH-8CH Module), L120 x W80 x H18 (9CH-18CH Module)

Applications

CATV systems
Active device termination
Telecommunication networks
Metro networks
Local Area Networks
Data processing networks
Test equipment
Premise installation
Wide Area Networks

Company Profile

New Light Optics Technology Limited is a high-tech company specializing in the R&D, manufacturing, sales and service of optical communication products. Established in 2011, our factory has 6 years of OEM and manufacturing experience serving customers worldwide.

Our product line includes: Patch Cord/Pigtails, Patch Cord Cables, MTP/MPO Patch Cord, Fiber Optical Adapters, Attenuators, Fiber Optical Connectors, and more. Our products are widely used in telecommunications, fiber optical CATV, digital internet fiber transmission, data base stations, and related applications.

We maintain high-tech capabilities, professional R&D teams, advanced production equipment, and sophisticated engineering skills. With a high-quality control system, our products are delivered to over 60 countries and areas including USA, Europe, Brazil, Middle East, and Asia.

Packaging & Shipping

Packaging: Bags & carton boxes
Shipping: International Express via FedEx, DHL, UPS, TNT and EMS, or by sea
FedEx Overnight: 1-3 business days for delivery
DHL: 2-4 business days for delivery (longer for Spain, Italy, Brazil and some countries due to customs)

Payment Terms

Payment Methods: T/T, PAYPAL, Western Union, Money Gram, L/C

Terms: 30% deposit in advance, 70% balance paid before delivery

Our Services

"One to one" dedicated service: Sales representatives serve only five clients each
Complete after-sales service: 24-hour designated telephone number, email and customer manager
Long warranty: 3 years warranty with free polishing or testing for non-artificially damaged cables (customer pays freight)
