SC PC MINI Fiber Optic Splitter Single Mode Low Insertion Loss FTTH / CATV Application

SC PC MINI Fiber Optic Splitter Single Mode Low Insertion Loss FTTH / CATV Application

    • SC PC MINI Fiber Optic Splitter Single Mode Low Insertion Loss FTTH  / CATV Application
    • SC PC MINI Fiber Optic Splitter Single Mode Low Insertion Loss FTTH  / CATV Application
  • SC PC MINI Fiber Optic Splitter Single Mode Low Insertion Loss FTTH  / CATV Application

    Product Details:

    Place of Origin: Shenzhen China
    Brand Name: New Light
    Certification: CE , ISO ,RoSH
    Model Number: LC / FC / SC / ST / E2000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pcs
    Price: can be negotiated
    Packaging Details: foam + carton box
    Delivery Time: 2-10 working days
    Payment Terms: L/C, T/T, Western Union, MoneyGram, paypal
    Supply Ability: 2000 pcs per month
    Contact Now
    Detailed Product Description
    Brand Name: New Light Fiber Type: 0.9 /2.0 / 3.0 Mm
    Connector Type: LC / FC / SC / ST / E2000 Core Type: SC PC
    Operating Wave: 1260-1650 Mode Type: Single Mode
    OEM / ODM: Acceptable Fiber Length: As Your Requirement
    Warranty: 3 Years Delivery Time: 2-10 Working Days After Receive Payment
    Payment: T/T , L/C , Paypal , Westen Union , Money Gram Products Name: SC PC MINI Splitter Fiber Optic Splitter PLC For FTTH / CATV Application





    Description



    SC PC MINI splitter fiber optic splitter PLC for FTTH / CATV application



    Feature


    • Adopt high strength stainless steel, pass salt spray test
    • Ferrule core is less than 0.5um
    • Adopt 100% new raw material, ROHS compliance
    • Low Insertion loss
    • Low PDL Compact Design
    • Good channel-to-channel uniformity
    • Wide Operating Wavelength: from 1260nm to 1650nm
    • Wide Operating Temperature: from -40℃ to 85℃


    900um FTTH Optic Fiber 1x2 Mini Module PLC Splitter. PLC Splitter is a kind of integrated wave guide optical power distribution devices based on quartz substrate, which has the advantages of small volume, wide operating of beam split. It suitable for connecting in the local side and terminal of the passive optical networks (EPON, BPON, GPON), at the same time, it realize optical signal split. PLC splitter is responsible to distribute optical signals rom Central Office to multiple premise locations. All products meet GR-1209 and GR-1221 requirements.
    Application

    Parameter4 Channel8 Channel16 Channel
    MuxDemuxMuxDemuxMuxDemux
    Channel Wavelength(nm)1270~1610
    Center wavelength Accuracy(nm)±0.5
    Channel Spacing(nm)20
    Channel Pass band(@-0.5dB bandwidth (nm)>14
    Insertion Loss(dB)≤1.4≤2.6≤5.0
    Channel Uniformity (dB)≤0.5≤0.5≤0.5
    Channel Ripple (dB)0.3
    Isolation (dB)AdjacentN/A>30N/A>30N/A>30
     Non-adjacentN/A>40N/A>40N/A>40
    Insertion Loss Temperature Sensitivity (dB/℃)<0.005
    Wavelength Temperature Shifting (nm/℃)<0.002
    Polarization Dependent Loss (dB)<0.1
    Polarization Mode Dispersion (PS)<0.1
    Directivity (dB)>50
    Return Loss(dB)>45
    Maximum Power Handling(mW)500
    Operating Temperature(℃)-5~+75
    Storage Temperature (℃)-40~85
    Package dimension(mm)1. L100 x W80 x H10 ( 2 CH~8CH Module)
    2. L120xW800xH18 (9 CH~18CH Module)



    • CATV;
    • Active device termination;
    • Telecommunication networks;
    • Metro;
    • Local Area Networks;
    • Data processing networks;
    • Test equipment;
    • Premise installation;
    • Wide Area Networks



    Company Introduction


    New Light Optics Technology Limited specialized in the Optical communication products R & D, manufacture,sales and service as high-tech company.Our factory was established in 2011 and with 6 years OEM and manufacture experience for customer all over the world.

    Our product line include: Patch Cord/Pigtails,Patch Cord Cables,MTP/MPO Patch Cord,Fiber Optical adapter, attenuator, Fiber optical connector... Etc. Our products widely used in Telecommunication,Fiber optical CATV, digital internet fiber transmit,data base station,etc.

    Company have high tech technology, professional R & D team, advanced production equipment,sophisticate skill engineers. And high quality control system,our products offer to customers to USA,European,Brazil,Middle East,and Asia more than 60 countries and areas.

    Products with high reputation and feedback from all customers!

    Please contact us if any we can support and cooperate together!



    Packing



    • Packaging : bags&carton box
    • Shipping: International Express: Fedex, DHL, UPS, TNT and EMS , or by sea ..If you have another

    preferred carrier, please notify us in advance.

    • FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
    • DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.




    Delivery and payment


    1. T/T/ , PAYPAL , WESTEN UNION , MONEY GRAM , L/C .
    2. 30% deposit in advance , 70% balance paid before delivery .



    Our Services

    • "One to one" heart to heart service: Sales representative serve for five clients only. We look forward the continuing long-term services for you, but not just one or two times' co-operation.
    • Perfect after-sales service :24-hour designated telephone number, e-mail and customer manager
    • Long warranty : 3 years warranty . We can polish or test it for free if the cable is not artificial damaged . (but you need to pay for freight ) .
