ST APC Connector Fiber Optic Pigtail with 0.3 dB Insertion Loss and 12 Core Bounded Tube

Brand Name: New Light
Model Number: SC/ PC
MOQ: 1
Price: 0.2~10
Packaging Details: OPP bag + carton box
Payment Terms: L/C,T/T,Western Union,MoneyGram,paypal
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE , ISO , RoHS
Products Name:
ST APC Yellow Optic Fiber Pigtail Bounded Tube Pigtail Optical Fibre Pigtail
Connector Type:
ST APC ( Can Be SC , FC , LC , MPO , MTRJ , MU )
Cable Type:
12 Core
Cable Color:
According To Your Request
Cable Diameter:
0.9mm
Cable Length:
(can Be Customized )
Insertion Loss:
≤ 0.3 DB
Return Loss:
≥ 60dB
Delivery Time:
2-7 Working Days
Payment Term:
30% Deposit In Advance , 70% Balance Paid Before Delivery
Supply Ability:
1000000
Highlight:

pigtail fiber optic cable

,

single mode fiber pigtails

Product Description
Yellow Fiber Optic Pigtail Bounded Tube ST APC 0.3 DB Insertion Loss
ST APC yellow optic fiber pigtail bounded tube pigtail optical fibre pigtail
Product Overview
Colorful Customized Optic Fiber Pigtail 12 Core FC Pigtail. SC FC LC ST optical fiber connector is the two end precision optical fiber optic jumper, dock up according to the transmission medium can be divided into common silicon-based optical single-mode, multi-mode jumpers, and other such as plastic for transmission medium of fiber optic jumper cables.
Available connector types: FC, SC, ST, LC, MTRJ, MPO, MU, SMA, FDDI, E2000, DIN4, D4 and various other forms.
Optical Performance Specifications
Content Testing Condition SM MM APC UPC PC
Optical Performance IL(dB) 1310/1550nm LD Light 0.2 0.2 0.2 0.2 0.2
RL(dB) 1310/1550nm LD Light 65 55 50 35 -
Environmental Performance
Test Conditions Result (dB)
High Temperature +85℃, 168H 0.2
Temperature Cycle -40~+75℃, 21 cycle, 168H 0.2
Humidity Thermal (Fixed) 5℃, 95% R.H., 168H 0.2
Humidity Thermal Cycle 10~+65℃, 95% R.H., 21 cycle, 168H 0.2
Mechanical Performance
Test Conditions Result (dB)
Vibration 10~55Hz, 1.5mm(p-p) 0.1
Bending 0.9kgf, -90°~+90°, 100 cycle 0.1
Torsion 2.5kgf, 10times/min, ±180°, 200times 0.1
Anti-tension 90N, 10min 0.1
Dropping 1.5 height, 8 times 0.2
Repeat 10 Times inserts 0.1
Durability >1000 times 0.2
Mechanical Performance & Operating Conditions
Content Character Unit
Working Temperature -40~+85 ℃
Storage Temperature -5~+50 ℃
Φ3.0 Fibre Curl Radius >30 mm
Φ3.0 Anti-Tensile Strength >9.0 Kgf
Main Mechanical Size SEE LAYOUT -
3D Index Specifications
Type Content APC UPC LC
Radius of Curvature (mm) 5-12 10-25 7-25
Apex Offset (um) 0~+50 - -
Fiber Height (nm) -50~+50 - -
Angle (deg) 7.5~8.5 / /
ST APC Connector Fiber Optic Pigtail with 0.3 dB Insertion Loss and 12 Core Bounded Tube 0 ST APC Connector Fiber Optic Pigtail with 0.3 dB Insertion Loss and 12 Core Bounded Tube 1
Company Profile
New Light Optics Technology Limited specializes in optical communication products R&D, manufacturing, sales and service as a high-tech company. Our factory was established in 2011 and has over 6 years of OEM and manufacturing experience serving customers worldwide.
Our product line includes: Patch Cord/Pigtails, Patch Cord Cables, MTP/MPO Patch Cord, Fiber Optical Adapter, Attenuator, Fiber Optical Connector, and more. Our products are widely used in Telecommunications, Fiber Optical CATV, digital internet fiber transmission, data base stations, and related applications.
The company features high-tech technology, professional R&D teams, advanced production equipment, and sophisticated engineering skills. With a high-quality control system, our products are delivered to over 60 countries and areas including USA, Europe, Brazil, Middle East, and Asia, receiving high reputation and positive feedback from all customers.
Please contact us for support and cooperation opportunities!
Payment Terms & Delivery
  • Payment Methods: T/T, L/C, Paypal, Western Union, Moneygram
  • Payment Terms: 30% deposit in advance, 70% balance paid before delivery
  • Packaging: International standard package (OPP bag + Carton Box)
  • Delivery Time: 2-7 working days (depending on quantity) after receiving payment
  • Warranty: 3 years after delivery
  • Shipping Methods: By air (DHL, TNT, UPS, Fedex), By sea (according to requirements)
