Home > Products >

Fiber Optic Pigtail

Yellow Fiber Optic Pigtail Bounded Tube ST APC 0.3 DB Insertion Loss

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

Yellow Fiber Optic Pigtail Bounded Tube ST APC 0.3 DB Insertion Loss

Brand Name:	New Light
Model Number:	SC/ PC
MOQ:	1
Price:	0.2~10
Packaging Details:	OPP bag + carton box
Payment Terms:	L/C, T/T, Western Union, MoneyGram , paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE , ISO , RoHS

Products Name:

ST APC Yellow Optic Fiber Pigtail Bounded Tube Pigtail Optical Fibre Pigtail

Connector Type:

ST APC ( Can Be SC , FC , LC , MPO , MTRJ , MU )

Cable Type:

12 Core

Cable Color:

According To Your Request

Cable Diameter:

0.9mm

Cable Length:

(can Be Customized )

Insertion Loss:

≤ 0.3 DB

Return Loss:

≥ 60dB

Delivery Time:

2-7 Working Days

Payment Term:

30% Deposit In Advance , 70% Balance Paid Before Delivery

Supply Ability:

1000000

Highlight:

pigtail fiber optic cable

single mode fiber pigtails

Product Description

ST APC yellow optic fiber pigtail bounded tube pigtail optical fibre pigtail

Description

Colorful Customized Optic Fiber Pigtail 12 Core FC Pigtail. SC FC LC ST optical fiber connector is the two end precision optical fiber optic jumper, dock up according to the transmission medium can be divided into common silicon-based optical single-mode, multi-mode jumpers, and other such as plastic for transmission medium of fiber optic jumper cables, By connecting head structure forms can be divided into: FC , SC,ST , LC , MTRJ , MPO, MU, SMA , FDDI , E2000 , DIN4 , D4 etc various forms.

1.Optical Feature:

Content		Testing Condition	(dB)
			SM			MM
			APC	UPC	PC
Optical Performance	IL(dB)	1310/1550nm LD Light	0.2	0.2	0.2	0.2
	RL(dB)	1310/1550nm LD Light	65	55	50	35
Environment Performance	High Temperature	+85℃,168H	0.2
	Temperature cycle	-40~+75℃,21cycle,168H	0.2
	Humidity thermal(Fixed)	5℃,95%R.H.,168H	0.2
	Humidity thermal cycle	10~+65℃,95%R.H.,21 cycle,168H	0.2
Mechanical Performance	Vibration	10~55Hz,1.5mm(p-p)	0.1
	Bending	0.9kgf,-90°~+90°,100cycle	0.1
	Torsion	2.5kgf,10times/min,±180°,200times	0.1n
	Anti-tension	90N,10min	0.1
	Dropping	1.5 height, 8 times	0.2
	Repeat	10 Times inserts	0.1
	Durability	>1000times	0.2

2. Mechanical Performance and Working temperature

Content	Character	Unit
Working Temperature	-40~+85	℃
Storage Temperature	-5~+50	℃
Φ3.0 Fibre Curl Radius	>30	mm
Φ3.0 Anti-Tensile Strength	>9.0	Kgf
Main Mechanical Size	SEE LAYOUT	-

3. 3D Index

Type Content	APC	UPC		LC
Radius of Cury(mm)	5-12	10-25		7-25
Apexoffset(um)	0~+50
FiberHeight(nm)	-50~+50
Angle(deg)	7.5~8.5		/		/

Yellow Fiber Optic Pigtail Bounded Tube ST APC 0.3 DB Insertion Loss 0

Yellow Fiber Optic Pigtail Bounded Tube ST APC 0.3 DB Insertion Loss 1

Company introduction

New Light Optics Technology Limited specialized in the Optical communication products R & D, manufacture,sales and service as high-tech company.Our factory was established in 2011 and with 6 years OEM and manufacture experience for customer all over the world.

Our product line include: Patch Cord/Pigtails,Patch Cord Cables,MTP/MPO Patch Cord,Fiber Optical adapter, attenuator, Fiber optical connector... Etc. Our products widely used in Telecommunication,Fiber optical CATV, digital internet fiber transmit,data base station,etc.

Company have high tech technology, professional R & D team, advanced productionequipment,sophisticate skill engineers. And high quality control system,our products offer to customers to USA,European,Brazil,Middle East,and Asia more than 60 countries and areas.Products with high reputation and feedback from all customers!

Please contact us if any we can support and cooperate together!

Payment term and delivery

1. Payment : T/T , L/C , Paypal , Westen Union , Moneygram

2. 30% deposit in advance , 70% balance paid before delivery .

3. Package : internatinal standard package ( OPP bag + Carton Box )

4. Delivery time : 2-7 working days ( according to your quantity )after received payment .

5. Warranty : 3 year (after delivery ) .

6. Shipping method : BY air ( DHL , TNT , UPS ,Fedex ) , By sea (according to your requirements ).
