1U Rack Mountable Fiber Optic Patch Panel with 96core LC and SPCC Black Coating for Data Centers

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

1U Rack Mountable Fiber Optic Patch Panel with 96core LC and SPCC Black Coating for Data Centers

Brand Name:	NL
Model Number:	1U
MOQ:	1~10000
Price:	10~100
Packaging Details:	Nomal packing 49526055mm

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001

Material:

SPCC (black Coating)

Standard:

Installation:

Standard EIA 19" Rack Rails

Enclosure Type:

Rack Mountable

No. Of Rack Spaces:

Fiber Count:

96core LC

Dimensions (HxWxD):

430*362.4*44mm

Material Thick:

1.2T

Patch Pannel:

SC/LC/FC/ST

Adaptor:

SC/LC/FC/ST/E2000/MPO/MTP

Combination:

Pull-type Box

Apply To:

Data Center & Cloud Computing

Supply Ability:

1000set per day

Highlight:

odf optical fiber distribution frame

odf fiber optic patch panel

Product Description

1U Rack Mount FHD Fiber Optic Patch Panel

This 1U rack mount fiber optic patch panel holds up to 4x MTP-8 cassettes, providing high-density fiber management for data centers and network installations.

Product Overview

The removable front panel chassis features a 19-inch 1U sliding design with two components: a sliding chassis and a front panel that accommodates optical adapters. This flexible two-piece construction allows you to maintain chassis inventory and attach appropriate front panels as needed.

Key Features

Standard 19-inch rack size with lightweight, rational structure
Compatible with FC, SC, ST, and LC adapter patch panels
Front access panel design for easy operation and maintenance
Snap-in lock design for quick component changes
Compatible with 19-inch standard optical distribution cabinets
Maximum capacity of 24 fibers
4 fiber cable entry ports at rear side
Constructed from SPCC with black coating

Applications

SPCC black coating fiber optic distribution frames provide interconnect or cross-connect functionality between backbone horizontal cables and active equipment while minimizing rack space usage. These enclosures support easy installation of pre-terminated solutions and are ideal for ultra high-density fiber applications in data centers, equipment rooms, and central offices.

Product Specifications

Specification	Details
Rack Spaces	1U
Fiber Count	96-core LC; 48-core SC
Enclosure Type	Rack Mountable
Material	SPCC (Black Coating)
Installation Standard	EIA 19" Rack Rails
Dimensions (HxWxD)	430 * 362.4 * 44mm

Standards Compliance

TIA/EIA-568-C.3

Network Layout Application

Create a modular cabling environment within your data center to accelerate application deployment, reduce costs, and streamline fiber cabling operations.

Technical Specifications

Parameter	Singlemode	Multimode
Polish	PC, APC	PC
Insertion Loss (Standard)	≤0.7dB	≤0.6dB
Insertion Loss (Elite Low Loss)	≤0.35dB	≤0.35dB
Return Loss	PC≥50dB; APC≥60dB	≥30dB
Test Wavelength	1310/1550nm	850/1310nm
Durability (500 Matings)	≤0.2dB
Operating Temperature	-20℃ to +70℃
Storage Temperature	-40℃ to +85℃
Fire Resistant	IEC 60794-2-30
Fiber Type	OS2, OM1, OM2, OM3, OM4
Cord Type	8, 12, 24, 48, 72, 96, 144 cores
Cable Diameter	3.0mm (8/12/24 core), 5.5mm (24 core), or customized
Cable Jacket	LSZH, OFNR, OFNP
Length	0.3m, 1m, 2m, 5m, 10m, 25m, 50m, 100m
