Good price online

products details

Home > Products >
Fiber Optic Patch Panel
>
Fiber Optic Distribution Frame MPO/MTP Cassette with 16C/32C Ribbon Fiber and Low Insertion Loss 0.35dB for Data Center
All Category

Optical Fiber Patch Cord

MPO MTP Patch Cord

MPO MTP Cable

MPO Cassette Module

Fiber Optic Patch Panel

Fiber Optic Pigtail

FTTH Termination Box

Fiber Optic Connectors

Quick Assembly Connector

Fiber Optic Adapter

Fiber Optic Attenuator

Fiber Optic Loopback

Fiber Optic Cables

Fiber Optic Tools

Fiber Optic Transceiver

Fiber Optic Splitter

Fiber Optic WDM

Fiber Optic Splice Closure

Copper Patch Cords

Rj45 Patch Panel

RJ45 Ethernet Connector

Drone Fiber Optic

Switch And Socket
Contact Us
Mrs. Alice
sales03@newlightfiber.com
0086-13534063703
wechat 86 13534063703
Contact Now
name
  • name
  • name
  • name

Fiber Optic Distribution Frame MPO/MTP Cassette with 16C/32C Ribbon Fiber and Low Insertion Loss 0.35dB for Data Center

Brand Name: NL
Model Number: rack mount
MOQ: 1~10000
Price: 10~100
Packaging Details: carton box
Payment Terms: L/C,T/T
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ISO9001
Fiber:
16C , 32C ,24C ,8C , 12C , 48C ,96C
Material:
Specc
Color:
Black Or Customized
Application:
Date Center
Feature:
Applies To 3.6mm Round Cable And 16C/32C Ribbon Fiber
Connector:
MPO / MTP
Mode:
SM, MM,MMLL,16C,32C , 24C
Spring:
Oval Spring
Cable:
3.6mm Round Cable And 16C/32C Ribbon Fiber
Insertion Loss:
0.35dB ; 0.5dB
Supply Ability:
1000 set per days
Highlight:

odf fiber optic patch panel

,

fiber optic distribution box

Product Description
Ribbon Fiber Optic Distribution Frame MPO/MTP Cassette for Data Center Applications
MPO/MTP Cassette 8C 12C 24C 32C 48C Ribbon Fiber Optic Patch Panel
Product Overview
MTP/MPO connectors are designed to interconnect cassettes, panels, or fan-outs, available in standard 8, 12, 24, or 48 core versions using a compact and rugged microcable structure. The compact cable design optimizes cableway utilization and improves airflow. These MPO/MTP cables are manufactured with premium quality components, with low loss elite versions available for demanding high-speed networks where power budgets are critical.
OEM/ODM Services
We offer various MPO connectors to meet your specific requirements. Compatible with 3.6mm round cable and 16C/32C ribbon fiber configurations.
Fiber Optic Distribution Frame MPO/MTP Cassette with 16C/32C Ribbon Fiber and Low Insertion Loss 0.35dB for Data Center 0
Technical Specifications
Items Elite Performance Standard Performance
SM MM SM MM
Insertion Loss 16F: ≤0.35dB
32F: ≤0.5dB		 16F: ≤0.35dB
32F: ≤0.7dB		 16F,32F: ≤0.7dB
Return Loss ≥55dB ≥20dB ≥55dB ≥20dB
Durability 500 cycles
Operation Temperature -40℃ to +85℃
Fiber Type OS2/OM3/OM4/OM5
Key Features
  • 100% pre-terminated and factory tested to ensure optimal transfer performance
  • Rapid configuration and networking capabilities reduce installation time
  • Supports 40G and 100G network applications
  • Jacket material options: LSZH, OFNR, OFNP available
  • Supports up to 12F, 24F, 48F, 72F, 96F, 144F configurations with custom options available
Product Description
MPO connectors with multifiber technology are ideal for high-density applications in data centers and telecommunication systems. They utilize high-precision metal guide pins and ferrule pin holes to ensure precise optical alignment. Available in SM, MM, MMLL, 16C, 32C configurations with high-force spring options.
Fiber Optic Distribution Frame MPO/MTP Cassette with 16C/32C Ribbon Fiber and Low Insertion Loss 0.35dB for Data Center 1
Applications
  • Telecom networks
  • Ethernet networks
  • Optical communication equipment
Mechanical Properties
Item Criteria Conformance
△IL After 50 Matings MPO/MTP: ≤0.3dB GR-1435
△IL After 500 Matings LC/SC/FC/ST: ≤0.2dB IEC 61300-2-2
Min Bend Radius (Dynamic) 20*OD (Cable Diameter) -
Min Bend Radius (Static) 15*OD (Cable Diameter) -
Environmental Conditions
Item Criteria Conformance
Operation Temperature -40°C to 60°C IEC 61753-1
Storage Temperature -45°C to 85°C -
Compliance & Standards
Compliant with IEC 61754-7 and GR-1435 standards. Meets RoHS/REACH requirements and UL94-V0 flammability grade.
Testing Notes
1. Test wavelength: SM@1310/1550nm, MM@850/1300nm
2. Standard conformance: GR-326, GR-1435
