Black LC Duplex 24 Port Fiber Optic Patch Panel with Clip Installation for 1U Rack Mount Distribution Box

Brand Name:	New Light
Model Number:	LC
MOQ:	1~10000
Price:	10~100
Packaging Details:	opp bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

ISO,RoHS , CE

Material:

Plastic

Port Count:

12 Duplex LC

Color:

Black

Application:

19inch 1U Distribution Box

Max Fiber Count:

24 Fiber LC

Suitable For:

SC / LC / MPO

Installation Method:

Clip

OEM /ODM:

Acceptable

Warranty:

1 Year After Delivery

Supply Ability:

20000 pcs per month

Highlight:

fiber optic parts and accessories

fiber optic accessories

Product Description

Black LC Insert Duplex Fiber Optic Patch Panel - 24 Port for 1U Distribution Box

This black LC duplex 24-port fiber optic patch panel is designed specifically for 1U distribution boxes. Each 1U distribution box accommodates 4 ports, with each port configurable for SC, LC, MPO, or E2000 type patch panels.

For LC connectors, the patch panel features 6 duplex adapters, with the bottom 6 ports covered by protective plastic clips as shown in the product images.

Designed for standard 19-inch 1U distribution frames (also known as distribution boxes), this patch panel offers easy installation and replacement when maintenance is required.

This plastic LC duplex 24-port fiber optic patch panel is exclusively compatible with our 1U distribution boxes. The innovative clip-on side design eliminates the need for screws, providing convenient installation and maintenance.

The panel supports both single mode and multimode fiber configurations according to your requirements, accommodating up to 24 fiber LC connectors using 12 duplex LC adapters.

Constructed from durable plastic material, this patch panel offers cost-effective shipping benefits and eliminates rust concerns during operation. This modern design has gained significant popularity in current market applications.

Specifically designed for wiring fiber optic pigtail type 1U distribution boxes, this solution provides reliable connectivity and organization.

Application Example

Features and Benefits

Multiple adapter options for flexible configuration
Compatible with standard 19" rack systems
45° open working angle for easy access
Supports up to 48 fibers in 1U space

Applications

Indoor applications
Data centers
Telecommunication networks
Premise installations
Data communication systems

Specifications

Attribute	Value
Material	Plastic
Number of Ports	24 fiber LC
Mode Type	Single mode / Multimode
Simplex/Duplex	Duplex LC
Rack Height	1U 19 inch
Color	Black

How to Order

Specify connector type: LC / SC / ST / E2000
Choose simplex or duplex configuration
Select fiber count: 12 fiber / 24 fiber / 48 fiber / 96 fiber
Specify 1U box size requirements
Provide quantity needed
