19 Inch Slide-out Drawer Fiber Optic Patch Panel with 12/24/48/72/96 Fiber Capacity for Data Centers

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

19 Inch Slide-out Drawer Fiber Optic Patch Panel with 12/24/48/72/96 Fiber Capacity for Data Centers

Brand Name:	New light
Model Number:	24 /48 core ptach panel
MOQ:	1~10000
Price:	10~100
Packaging Details:	opp bag+Carton box
Payment Terms:	T/T,Western Union,MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ROHS ;ISO9001

Aplication:

Data Centers,pre-terminated Installations

Front Panel:

LC , SC , ST , FC , E2000

Size:

19 Inch

Interface:

Powder Coated

Product Name:

24 Fiber Rack Mounted MPO/MTP Fiber Optic Patch Panel

Tray:

12/24/48/72/96 Fiber

Weight:

Material:

Phosphor Bronze

Storage Temperature:

-45°C~+60°C

Product Type:

Slide-out Drawer Enclosure With Splice Trays

Dimensions:

1.75"H X 17.0"W X 14.0"D,485mmx294mmx44mm

Type:

2U,draw Type Fiber Optic Path Panel,1U,Singlemode Or Mutil Mode

Supply Ability:

10000 per day

Highlight:

fiber optic parts and accessories

fiber optic accessories

Product Description

Single Mode Fiber Optic Enclosure - SC/FC Patch Panel

19-inch 12-core SC/FC single-mode fiber optic rack mount patch panel designed for professional fiber optic cable management and distribution.

Product Overview

The Fiber Optic Terminal Box is engineered for distributing and protecting optical fiber links in FTTH networks. Constructed from high-quality cold-rolled steel sheet with static plastic spraying treatment, this indoor rack-mount chassis provides reliable terminal connection for various fiber optic systems.

Note: This unit does not include adapters or pigtails. Optional installation services available upon request.

Key Specifications

Parameter	Unit	FDF-1U	FDF-2U	FDF-3U
Fiber Capacity	Core	≤24	≤48	≤72
Number of Tray	PCS	1	2	4
Height		1U	2U	3U
Dimension Width	mm	482	482	482
Dimension Depth	mm	305	305	305
Remark		Rack Mount	Rack Mount	Rack Mount

Technical Features

MTP/MPO standard compliant multifiber connector
LC (SFF data center standard), SC discrete interface
OS1/2, OM3, OM4 fiber grades (OM1 and OM2 available)
12 and 24 fiber versions - 12 LC (Duplex) / SC (Simplex) optical parts
Polarity A (standard), B or C
Factory terminated and tested
High performance zirconia sleeve adaptors
Low excess loss & high performance
Retractable splicing tray
Convenience and ease of handling

Environmental Specifications

Parameter	Specification
Operating temperature	-25℃ ~ +40℃
Storage temperature	-25℃ ~ +55℃
Relative humidity	≤85％ (+30℃)
Air pressure	70Kpa ~ 106Kpa
Color	Black

Applications

Telecommunication networks
Local Area Networks
FTTH (Fiber to the Home)
CATV networks
Active device termination

Physical Dimensions

Model	Fiber Quantity	Height	Dimension (LxWxH)
Rack Mount	12/24/48/96 core	1U	430 * 354.1 * 44mm
