Optical Fiber Patch Cord

Customizable Length Simplex Single Mode LC-LC Fiber Optic Patch Cord for High-Speed Data Transmission

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

Customizable Length Simplex Single Mode LC-LC Fiber Optic Patch Cord for High-Speed Data Transmission

Brand Name:	NewLight
Model Number:	NL001
MOQ:	1~100000
Price:	0.1~100
Packaging Details:	1 pcs per pack
Payment Terms:	T/T,Western Union,MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Name:

LC-LC Fiber Patch Cord

Diameter:

2.0mm

Model:

Single

Connector:

LC-LC

Color:

Yellow

Fiber Type:

Simplex And Duplex

Application:

FTTH FTTB FTTX Network,FTTA FTTH BBU RRU RRH LTE & Base Station,For ODF Internal Link,For Room Equipment Internal Link,FTTH/Test Equipments/TV/LAN/Telecommunication Equipments

Length:

Any Length Is Customizable

Connector Type:

SC/FC/LC/ST/MU/DIN/D4/MTRJ/MPO

Name:

LC-LC Fiber Patch Cord

Diameter:

2.0mm

Model:

Single

Connector:

LC-LC

Color:

Yellow

Fiber Type:

Simplex And Duplex

Application:

FTTH FTTB FTTX Network,FTTA FTTH BBU RRU RRH LTE & Base Station,For ODF Internal Link,For Room Equipment Internal Link,FTTH/Test Equipments/TV/LAN/Telecommunication Equipments

Length:

Any Length Is Customizable

Connector Type:

SC/FC/LC/ST/MU/DIN/D4/MTRJ/MPO

Supply Ability:

1000000

Highlight:

single mode fiber optic cable

duplex fiber patch cord

Product Description

Customized Patch Cord Optical Fiber - Simplex Single Mode FC to LC

This high-quality simplex single mode FC to LC fiber patch cord provides a cost-effective solution for high bandwidth and transmission rates over short distances. Available in both singlemode and multimode versions, each connection offers exceptional durability and resistance to pulls, strains, and impacts during installation.

Product Overview

Optical Fiber Patch Cords (Jumpers) are lengths of optical fiber with connectors on both ends to connect beam paths. Our patch cords are assembled with various connector types and employ advanced manufacturing techniques to ensure consistent high quality in mass production.

Ordering Options

Both singlemode and multimode fiber optic patch cords feature zirconia ceramic ferrules with pre-polished PC, UPC, or APC profiles and convex spherical ends. These end face types enable faster polishing while ensuring low back reflection, minimal optical loss, and maximum repeatability.

Technical Specifications

Parameter	Options
Connector Type	SC, FC, ST, LC, E2000, DIN, MU, MTRJ, etc.
Polish	UPC, APC, PC
Cable Type	Simplex, Duplex Straight, Duplex Reverse
Fiber	SM(G652), 62.5/125um, 50/125um, OM2, OM3, SM(G655)
Cable Jacket	Riser, Plenum, LSZH
Cable Diameter	3.0mm, 2.0mm, 0.9mm, etc.
Cable Length	Custom length in meters

Available Configurations

Connector types: FC, SC, ST, LC, MT-RJ, MU, etc.
Ferrule endface: PC, UPC, APC, etc.
Fiber types: Single mode, polarization-maintaining optical fiber, multimode 50/125, multimode 62.5/125, etc.
Cable diameters: 0.9mm, 2.0mm, 3.0mm, etc.
Number of fibers: Single-core, dual-core, and multi-core connectors

Detailed Specifications

Fiber Type	Single Mode Options	Multimode Options
Fiber Type	9/125-G652D, 9/125-G655, 9/125-G657A, G657A2, 9/125-G657B3	50/125-OM2, 62.5/125-OM1, 50/125-OM3, 50/125-OM4, 50/125-OM5
Fiber Brand	YOFC, Corning, Sumitomo, Fujikura
Connector	SC/PC, SC/APC, LC/PC, LC/APC, FC/PC, FC/APC, ST/PC, E2000/PC, E2000/APC, MU/PC, MTRJ/Female, MTRJ/Male, MPO/MTP, DIN/PC, SMA/PC, D4/PC
Cord Type	Simplex, Duplex
Cable Diameter	0.9mm, 1.2mm, 1.6mm, 1.8mm, 2.0mm, 2.8mm, 3.0mm, 4.1mm
Cable Jacket	PVC, OFNR, LSZH, OFNP
Length (M)	0.5m, 1m, 2m, 5m, 10m, 25m, 50m, 100m... Customized

Key Features

Excellent durability and exchangeability
High temperature stability
Low insertion loss and back reflection loss
Superior quality standard PC/UPC/APC polishing
Compliant with Telcordia GR-326-CORE, TIA/EIA and IEC standards
