Custom Length Multimode ST to LC Optical Fiber Patch Cord for High-Speed Data Transmission

Brand Name:	NewLight
Model Number:	NL001
MOQ:	1~100000
Price:	0.1~100
Packaging Details:	1 pcs per pack
Payment Terms:	T/T,Western Union,MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Fiber Type:

Simplex And Duplex

Application:

FTTH FTTB FTTX Network,FTTA FTTH BBU RRU RRH LTE & Base Station,For ODF Internal Link,For Room Equipment Internal Link,FTTH/Test Equipments/TV/LAN/Telecommunication Equipments

Length:

Any Length Is Customizable

Connector Type:

SC/FC/LC/ST/MU/DIN/D4/MTRJ/MPO

Type:

Single Mode/Multi-mode

Fiber Count:

Simplex Or Duplex

Material:

PVC/LSZH

Color:

Orange Or Others,aqua Or Cusomized

Repeatability:

≤ 0.2 DB,<=0.3dB

Polish:

PC/UPC/APC

Fiber Type:

Simplex And Duplex

Application:

FTTH FTTB FTTX Network,FTTA FTTH BBU RRU RRH LTE & Base Station,For ODF Internal Link,For Room Equipment Internal Link,FTTH/Test Equipments/TV/LAN/Telecommunication Equipments

Length:

Any Length Is Customizable

Connector Type:

SC/FC/LC/ST/MU/DIN/D4/MTRJ/MPO

Type:

Single Mode/Multi-mode

Fiber Count:

Simplex Or Duplex

Material:

PVC/LSZH

Color:

Orange Or Others,aqua Or Cusomized

Repeatability:

≤ 0.2 DB,<=0.3dB

Polish:

PC/UPC/APC

Supply Ability:

1000000

Highlight:

single mode fiber optic cable

duplex fiber patch cord

Product Description

Custom Multimode Optical Fiber Patch Cord

ST to LC duplex multimode fiber optic patch cord providing high bandwidth and transmission rates over short distances.

Product Overview

This high-quality multimode fiber optic patch cable is engineered for Ethernet applications, offering exceptional durability and resistance to pulls, strains, and impacts during installation. Available in both singlemode and multimode configurations.

Ordering Options

All fiber optic patch cords feature zirconia ceramic ferrules with pre-polished PC, UPC, or APC profiles and convex spherical ends for faster polishing, low back reflection, minimal optical loss, and maximum repeatability.

Connector Type	SC, FC, ST, LC, E2000, DIN, MU, MTRJ, etc.
Polish	UPC, APC, PC
Cable Type	Simplex, Duplex Straight, Duplex Reverse
Fiber	SM(G652), 62.5/125um, 50/125um, OM2, OM3, SM(G655)
Cable Jacket	Riser, Plenum, LSZH
Cable Diameter	3.0mm, 2.0mm, 0.9mm, etc.
Cable Length	Custom length in meters

Available Configurations

Connector types: FC, SC, ST, LC, MT-RJ, MU, etc.
Ferrule endface: PC, UPC, APC, etc.
Fiber types: Single mode, polarization-maintaining optical fiber, multimode 50/125, multimode 62.5/125, etc.
Cable diameters: 0.9mm, 2.0mm, 3.0mm, etc.
Number of fibers: Single-core, dual-core, and multi-core connectors

Technical Specifications

Fiber Type	Single Mode	Multimode
Options	9/125-G652D, 9/125-G655, 9/125-G657A, G657A2, 9/125-G657B3	50/125-OM2, 62.5/125-OM1, 50/125-OM3, 50/125-OM4, 50/125-OM5
Fiber Brand	YOFC, Corning, Sumitomo, Fujikura
Connector Types	SC/PC, SC/APC, LC/PC, LC/APC, FC/PC, FC/APC, ST/PC, E2000/PC, E2000/APC, MU/PC, MTRJ/Female, MTRJ/Male, MPO/MTP, DIN/PC, SMA/PC, D4/PC
Cord Type	Simplex, Duplex
Cable Diameter	0.9mm, 1.2mm, 1.6mm, 1.8mm, 2.0mm, 2.8mm, 3.0mm, 4.1mm
Cable Jacket	PVC, OFNR, LSZH, OFNP
Length Options	0.5m, 1m, 2m, 5m, 10m, 25m, 50m, 100m... Customized

Key Features

Excellent durability and exchangeability
High temperature stability
Low insertion loss and back reflection loss
Superior quality standard PC/UPC/APC polishing
Compliant with Telcordia GR-326-CORE, TIA/EIA and IEC standards
