12 Core OM4 MPO MTP Cable with Custom Length for High-Density Data Center Connectivity

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

12 Core OM4 MPO MTP Cable with Custom Length for High-Density Data Center Connectivity

Brand Name:	New Light
Model Number:	MPO / MTP - MPO / MTP
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Connector Type:

MPO / MTP TO MPO / MTP

Material:

LSZH, OFNP Or OFNR

Mode Type:

Core Type:

12 Core

Cable Color:

Magneta

Length:

Can Be Customized According To Your Requirements

Certificate:

CE , ISO , RoHS

Delivery Time:

2-7 Working Days After Received Deposit

Production Ability:

500 Pcs / Day

Payment Term:

T/T , 30% Deposit In Advance

Certification:

ISO9001

Supply Ability:

500 pcs per day

Highlight:

mpo to mpo cable

mpo fanout cable

Product Description

Multi Fiber Connector MTP Fiber Cable / Connect MPO Cassette Patch Panel

MTP 12 fiber connector MTP fiber cable connect MPO cassette patch panel for high-density data center applications.

MPO MTP Cable Overview

These OM3 fiber jumper cables feature a 50/125 configuration with aqua OFNP plenum-rated jacket material, designed for 100Gb networking. The MTP-MTP fiber optical cord is assembled with MTP female connectors featuring a spring-loaded sliding mechanism for secure latching onto adapters, ensuring reliable connections in data center environments. Each assembly undergoes 100% factory testing to meet Bellcore GR-326 and TIA/EIA standards with maximum insertion loss compliance.

MPO MTP Cable Applications

Single-mode or multi-mode options available
PC (physical contact) or APC (8 degree angled) configurations
Various insertion loss indexes and color options
Stable performance with PIN fixed positioning
Plug-type connector with locking structure
High-density design for efficient wiring and management

MPO MTP Cable Features

Telecom network infrastructure
System cabling solutions
Precision telecommunications equipment

MPO MTP Cable Technical Parameters

Item	Technical Parameters
Connector	MPO/MTP (Female or Male)
Operation Temperature	-40°C to +80°C
Storage Temperature	-40°C to +85°C
Insertion Loss	Single-mode: ≤ 0.75dB (standard), ≤0.35dB (typical); Multi-mode: ≤ 0.50dB (standard), ≤0.35dB (typical)
Return Loss	Single-mode: ≥60dB; Multi-mode: ≥35dB
MPO End Type	Male: with guide pin; Female: without guide pin
Fiber Count	8, 12 & 24 fiber
Connector Type (Other End)	MPO-female, MPO-male, FC, SC, ST, MU, LC, E2000
Fiber Mode	Single-mode (G652,G655,G657), multi-mode (50, 62.5, OM2, OM3, OM4)
Fiber Cable Type	250um ribbon fiber, ribbon cable, bundle fiber optic cable

The three polarity methods Type A, Type B and Type C are used to guarantee the right bi-directional allocation.

Packaging

Products are packaged in OPP bags with carton boxes for external protection to ensure safe delivery and prevent damage during transportation.

Contact: WHATSAPP +8613534063703

Frequently Asked Questions

Q: Are you a manufacturer?

A: Yes, we are a manufacturer located in Shenzhen, China.

Q: What's your minimum order quantity?

A: MOQ can be 1 piece, but we recommend larger quantities for better pricing as single-unit orders incur higher costs.

Q: What's the price?

A: Pricing is quantity-dependent. We provide our best pricing upon receiving your quantity requirements, with competitive rates for larger orders.

Q: Can you quote FOB price?

A: We can provide FOB quotes, but due to typical small size and weight, most shipments are via air couriers (DHL, TNT, UPS, FEDEX). We recommend providing detailed specifications and quantity for comprehensive pricing including freight. EXW or CFR pricing is often more suitable.

Q: How is your quality?

A: Our production follows IEC and European standards in near dust-free workshops using imported production and quality control equipment. All products undergo 100% testing before delivery.

Q: What's your lead time?

A: With three factories in China specializing in fiber optic cable production and patch cord manufacturing, we maintain 2-3 working day lead times for 5,000 pieces of patch cords. Regular products are typically in stock, and we accommodate urgent orders.

Q: What's your warranty?

A: Patch cords carry a 2-year warranty from delivery date covering non-artificial damage. For artificial damage, we provide free repairs with customer responsible for freight costs.

Q: What's your packaging?

A: We use international export packaging and can print your logo upon request.

Q: Can you do OEM/ODM?

A: Yes, we support OEM/ODM services and can sign confidentiality agreements.

Q: Can I have a sample?

A: Free samples are available for adaptors, attenuators, patch cords, and pigtails with customer covering freight costs. For high-value products, sample charges apply but are refundable upon order placement.

Q: How can I order?

A: 1. Contact us with product details, specifications, quantity, and shipping address. 2. We provide pricing and lead time. 3. Upon acceptance, we issue proforma invoice. 4. Production begins after payment. 5. We confirm shipping details and provide tracking. 6. We prioritize long-term partnership satisfaction.

Q: What are your payment terms?

A: We accept T/T, Western Union, PayPal, and MoneyGram. For large orders: 50% deposit with balance due before shipment.
